Omron OS32C-SN-4M安全激光扫描仪 PDF资料
1.产 品 资 料 介 绍：
Omron OS32C-SN-4M 安全激光扫描仪产品特点
Omron OS32C-SN-4M 是一款紧凑型Type 3安全激光扫描仪，具备4m防护区域和270°扫描角度，适用于AGV碰撞检测、设备入侵监测等工业安全应用。
以下是该型号的主要特点：
安全等级达PLd/安全类别3，符合ISO 13849-1及IEC 61496-1/-3标准。
最大防护距离4m，警告区域最远15m，270°宽角度覆盖。
最小检测物体可配置为φ30、40、50、70mm，适应不同精度需求。
响应时间80ms至680ms可调，灵活匹配工艺节拍。
支持70组区域设定（每组含1个安全区+2个警告区），适应复杂工况。
支持EtherNet/IP通信，可远程监控设备状态与测量数据。
采用脏污容许模式，减少因粉尘导致的误停机。
配备基准点监视功能，检测安装偏移时自动停止安全输出。
传感器模块可独立更换，配置存储在I/O模块中，无需重新编程。
防护等级IP65，适应工业现场环境。
功耗仅5W（待机3.75W），支持24V DC供电。
内置8个方向入侵指示灯和正面显示屏，状态一目了然。
提供背面出线和左侧出线两种型号，适配不同安装需求。
综上，Omron OS32C-SN-4M 凭借高安全等级、灵活的检测配置和便捷的维护特性，是工业自动化安全防护领域的可靠选择。
Omron OS32C-SN-4M Safety Laser Scanner Product Features
Omron OS32C-SN-4M is a compact Type 3 safety laser scanner with a 4m protection area and a 270 ° scanning angle, suitable for industrial safety applications such as AGV collision detection and equipment intrusion monitoring.
The following are the main features of this model:
The safety level reaches PLd/safety category 3 and complies with ISO 13849-1 and IEC 61496-1/-3 standards.
The maximum protection distance is 4m, the farthest warning area is 15m, and the coverage angle is 270 °.
The minimum detection object can be configured as diameter 30, 40, 50, or 70mm to meet different accuracy requirements.
The response time can be adjusted from 80ms to 680ms, flexibly matching the process rhythm.
Support 70 sets of area settings (each set includes 1 safety zone+2 warning zones) to adapt to complex working conditions.
Supports EtherNet/IP communication, allowing for remote monitoring of device status and measurement data.
Adopting a dirt tolerance mode to reduce false shutdowns caused by dust.
Equipped with benchmark monitoring function, automatically stopping safety output when detecting installation deviation.
The sensor module can be independently replaced, and the configuration is stored in the I/O module without the need for reprogramming.
Protection level IP65, suitable for industrial site environment.
Power consumption is only 5W (standby 3.75W), supporting 24V DC power supply.
Equipped with 8 directional intrusion indicator lights and a front display screen, the status is clear at a glance.
Provide two models of rear and left side output lines to meet different installation requirements.
Overall, Omron OS32C-SN-4M is a reliable choice in the field of industrial automation security protection due to its high security level, flexible detection configuration, and convenient maintenance features.
