GE SR745-W2-P1-G1-HI-A-L-R-E保护继电器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
GE SR745-W2-P1-G1-HI-A-L-R-E 保护继电器是GE Multilin生产的高级变压器保护和管理继电器，专门用于提供变压器的综合保护、控制和监视。它在电力行业中有广泛的应用，尤其是用于发电厂、变电站和工业设施中。以下是关于这款继电器的详细信息：
主要功能和特性
差动保护:
- 该继电器提供高灵敏度的差动保护功能，能够检测变压器绕组之间的差动电流，识别内部故障，如匝间短路、绕组接地故障等。
过流保护:
- 提供多种过流保护功能，包括瞬时过流、定时过流和反时限过流保护，确保在短路和其他异常电流情况下，迅速切断故障电路，保护变压器免受损坏。
过载保护:
- 监控变压器的负载情况，防止长时间的过载运行，避免因过热导致的绝缘损坏和设备寿命缩短。
温度监控:
- 内置温度监控功能，能够实时监测变压器的绕组和油温，提供报警和跳闸功能，以防止变压器过热。
励磁涌流阻断:
- 通过识别励磁涌流特征，防止误跳闸，确保变压器在投入运行时的稳定性。
通信功能:
- 支持多种通信协议（如Modbus、DNP3、IEC 61850等），能够与其他保护设备、控制系统进行数据交换，支持远程监控和控制。
事件记录和波形捕捉:
- 具有事件记录和波形捕捉功能，可以记录和分析电力系统的故障事件，为故障排查和系统优化提供数据支持。
自动化和控制:
- 支持自动化操作，例如自动重合闸、负载切换和故障隔离，提升系统的运行效率和可靠性。
英文资料：
The GE SR745-W2-P1-G1-HI-A-L-R-E protection relay is an advanced transformer protection and management relay produced by GE Multilin, specifically designed to provide comprehensive protection, control, and monitoring of transformers. It has a wide range of applications in the power industry, especially in power plants, substations, and industrial facilities. The following is detailed information about this relay:
Main functions and features
Differential protection:
This relay provides high sensitivity differential protection function, which can detect differential current between transformer windings, identify internal faults such as turn to turn short circuits, winding grounding faults, etc.
Overcurrent protection:
Provide multiple overcurrent protection functions, including instantaneous overcurrent, timed overcurrent, and inverse time overcurrent protection, to ensure that the fault circuit is quickly cut off in case of short circuit and other abnormal current situations, protecting the transformer from damage.
Overload protection:
Monitor the load condition of the transformer to prevent long-term overload operation, avoid insulation damage caused by overheating, and shorten equipment life.
Temperature monitoring:
Built in temperature monitoring function, capable of real-time monitoring of transformer windings and oil temperature, providing alarm and trip functions to prevent transformer overheating.
Excitation surge blocking:
By identifying the characteristics of excitation inrush current, it prevents false tripping and ensures the stability of the transformer during operation.
Communication function:
Supports multiple communication protocols (such as Modbus, DNP3, IEC 61850, etc.), can exchange data with other protection devices and control systems, and supports remote monitoring and control.
Event recording and waveform capture:
Equipped with event recording and waveform capture functions, it can record and analyze fault events in the power system, providing data support for fault diagnosis and system optimization.
Automation and Control:
Support automated operations such as automatic reclosing, load switching, and fault isolation to improve system efficiency and reliability.
