3BHB003688R0101总线接口模块
1.产 品 资 料 介 绍：
中文资料：
3BHB003688R0101总线接口模块的产品特点与规格归纳如下：
一、产品概述
3BHB003688R0101总线接口模块是ABB品牌的一款高性能产品，主要用于工业自动化系统中不同设备之间建立通信连接，以实现数据交换、控制和监测。
二、产品特点
- 高速传输：该总线接口模块支持高速数据传输，满足各种工业自动化应用的需求。
- 稳定性高：模块经过严格的质量控制和测试，具有较高的稳定性和可靠性，能在恶劣的工业环境下稳定运行。
- 易于配置和维护：提供友好的用户界面和工具，方便用户进行配置和调试。同时，具有自诊断功能，可以快速检测和定位故障，便于用户进行维护和维修。
- 兼容性强：支持多种总线通信协议，如Profibus、Modbus、CAN、Ethernet/IP等，可以与其他设备和系统进行无缝连接和通信。
三、产品规格
- 电气参数：
- 输入电压：24VDC
- 输出电压：24VDC
- 输出功率：360W
- 输入电压范围：100-240VAC
- 最大输出电流：15A
- 物理参数：
- 产品尺寸：115mm x 48mm x 150mm
- 产品重量：约1.2kg
- 环境参数：
- 工作温度范围：-25~70℃
- 存储温度范围：-40~85℃
- 外壳材质：铝制或不锈钢
四、用途
该总线接口模块主要用于工业自动化系统中，实现不同设备之间的总线通信，使它们能够相互连接、交换数据和控制信号，从而形成一个完整、协调工作的自动化系统。
综上所述，3BHB003688R0101总线接口模块凭借其高速传输、高稳定性、易于配置和维护、兼容性强等特点，以及明确的电气、物理和环境参数，在工业自动化领域具有广泛的应用前景。
英文资料
The product characteristics and specifications of 3BHB003688R0101 bus interface module are summarized as follows:
1、 Product Overview
3BHB003688R0101 bus interface module is a high-performance product of ABB brand, mainly used to establish communication connections between different devices in industrial automation systems to achieve data exchange, control, and monitoring.
2、 Product features
High speed transmission: This bus interface module supports high-speed data transmission, meeting the needs of various industrial automation applications.
High stability: The module has undergone strict quality control and testing, with high stability and reliability, and can operate stably in harsh industrial environments.
Easy to configure and maintain: Provides a user-friendly interface and tools for users to easily configure and debug. At the same time, it has a self diagnostic function, which can quickly detect and locate faults, making it easy for users to maintain and repair.
Strong compatibility: Supports multiple bus communication protocols, such as Profibus Modbus, CAN, Ethernet/IP, etc. can seamlessly connect and communicate with other devices and systems.
3、 Product specifications
Electrical parameters:
Input voltage: 24VDC
Output voltage: 24VDC
Output power: 360W
Input voltage range: 100-240VAC
Maximum output current: 15A
Physical parameters:
Product dimensions: 115mm x 48mm x 150mm
Product weight: approximately 1.2kg
Environmental parameters:
Working temperature range: -25~70 ℃
Storage temperature range: -40~85 ℃
Shell material: aluminum or stainless steel
4、 Purpose
This bus interface module is mainly used in industrial automation systems to achieve bus communication between different devices, enabling them to connect, exchange data and control signals, thereby forming a complete and coordinated automation system.
In summary, the 3BHB003688R0101 bus interface module has broad application prospects in the field of industrial automation due to its high-speed transmission, high stability, easy configuration and maintenance, strong compatibility, and clear electrical, physical, and environmental parameters.
2.产 品 展 示
3.产 品 展 示
