VMIVME-2510B-100 数字量输入模块
1.产 品 资 料 介 绍：
中文资料：
VMIVME-2510B-100数字量输入模块概述
VMIVME-2510B-100是一款功能强大的数字量输入模块，属于VMIC的Megamodule系列产品，具有以下主要特点和规格：
- 主要特点：
- 可编程性：每个8位端口的方向可单独编程，提供高度的灵活性和配置选项。
- 高接收器能力：具备64mA接收器能力（15mA源），适用于各种信号输入需求。
- 内置测试逻辑：设计有用于故障检测和隔离的内置测试逻辑，确保系统的高可靠性。
- DIN类型I/O连接器：采用高可靠性的DIN类型I/O连接器，确保信号传输的稳定性和可靠性。
- 支持多种数据传输：支持8位、16位、32位数据传输，满足不同系统的需求。
- 规格参数：
- 类型：VMIVME-2510B-100数字量输入模块
- 系列：Megamodule系列
- 品牌：VMIC
- 数据/控制寄存器：具有独立板地址译码功能
- 地址映射：设计有两套板卡地址开关，为CSR和I/O地址提供高效的内存地址映射
- 板级诊断：通过前面板故障指示灯实现板级诊断的可见性
英文资料
Overview of VMIVME-2510B-100 Digital Input Module
VMIVME-2510B-100 is a powerful digital input module belonging to the Megamodule series of VMIC, with the following main features and specifications:
Main features:
Programmability: The direction of each 8-bit port can be individually programmed, providing a high degree of flexibility and configuration options.
High receiver capability: Equipped with a 64mA receiver capability (15mA source), suitable for various signal input needs.
Built in testing logic: Designed with built-in testing logic for fault detection and isolation, ensuring high reliability of the system.
DIN type I/O connectors: High reliability DIN type I/O connectors are used to ensure the stability and reliability of signal transmission.
Supports multiple data transfers: supports 8-bit, 16 bit, and 32-bit data transfers to meet the needs of different systems.
Specification parameters:
Type: VMIVME-2510B-100 Digital Input Module
Series: Megamodule Series
Brand: VMIC
Data/Control Register: With independent board address decoding function
Address Mapping: Designed with two sets of board address switches, providing efficient memory address mapping for CSR and I/O addresses
Board level diagnosis: visibility of board level diagnosis is achieved through front panel fault indicator lights
2.产 品 展 示
3.产 品 展 示
