362A1052P004 火焰检测器 PDF资料
1.产 品 资 料 介 绍：
中文资料：
362A1052P004 是一款火焰检测器，通常用于工业燃烧过程中的火焰监测。这种类型的设备广泛应用于燃烧系统中，如锅炉、燃气发电机、加热器等，以确保燃烧过程的安全性和效率。
主要特点和功能
高灵敏度探测：
- 设计为能够检测到微弱的火焰信号，确保能够在燃烧过程中准确监测火焰状态。
多种探测技术：
- UV探测器：适用于高温火焰的监测，常用于燃烧器和锅炉中。
- IR探测器：适合检测不同波长的红外辐射，常用于多种燃烧过程中的火焰监测。
- 362A1052P004 火焰检测器可能采用紫外（UV）或红外（IR）探测技术，具体取决于型号和应用需求：
实时监测与报警：
- 提供实时火焰监测和报警功能，在火焰异常时发出警报，以防止设备损坏或潜在的安全隐患。
高可靠性与耐用性：
- 设计用于工业环境，具有耐高温、抗干扰的能力，确保长期稳定运行。
兼容性与集成：
- 可以与多种控制系统兼容，通常提供标准的输出信号（如开关量、4-20mA），便于与现有的控制系统集成。
故障诊断：
- 部分型号配备自诊断功能，能够自动检测并报告设备状态，帮助维护人员及时发现和解决问题。
技术规格（示例）
- 探测方式：紫外（UV）或红外（IR）探测（具体取决于型号）。
- 电源要求：例如24V DC、110V AC或220V AC，具体电源要求根据型号而定。
- 输出信号：通常包括开关量输出（继电器输出）、模拟信号（如4-20mA）等。
- 工作温度范围：一般设计为在-20°C到+70°C范围内可靠工作。
- 响应时间：快速响应，确保及时检测和报警。
应用领域
燃烧系统：
- 用于燃烧器、锅炉、加热器等设备中的火焰监测，确保燃烧过程的稳定性和安全性。
燃气发电机：
- 在燃气发电机中应用，监测火焰状态，防止设备损坏或停机。
石化和化工行业：
- 在石化和化工过程中监测火焰状态，确保生产过程的安全。
电力行业：
- 在电力行业的燃烧设备中使用，确保设备的安全运行和高效工作。
安装与维护
安装：
- 应将火焰检测器安装在能够有效监测火焰的位置，确保探测器的视线范围内没有障碍物，避免直接受到振动、灰尘或高温的影响。
维护：
- 定期检查和清洁探测窗口，以防止灰尘或污垢影响探测性能。
- 进行定期功能测试，确保设备在实际运行中的有效性和可靠性。
英文资料：
362A1052P004 is a flame detector commonly used for flame monitoring in industrial combustion processes. This type of equipment is widely used in combustion systems, such as boilers, gas generators, heaters, etc., to ensure the safety and efficiency of the combustion process.
Main features and functions
High sensitivity detection:
Designed to detect weak flame signals and ensure accurate monitoring of flame status during combustion.
Multiple detection techniques:
The 362A1052P004 flame detector may use ultraviolet (UV) or infrared (IR) detection technology, depending on the model and application requirements:
UV detector: suitable for monitoring high-temperature flames, commonly used in burners and boilers.
IR detector: suitable for detecting infrared radiation of different wavelengths, commonly used for flame monitoring in various combustion processes.
Real time monitoring and alarm:
Provide real-time flame monitoring and alarm functions, issuing alerts in case of abnormal flames to prevent equipment damage or potential safety hazards.
High reliability and durability:
Designed for industrial environments, it has the ability to withstand high temperatures and interference, ensuring long-term stable operation.
Compatibility and Integration:
It can be compatible with multiple control systems and usually provides standard output signals (such as switch values, 4-20mA), making it easy to integrate with existing control systems.
Fault diagnosis:
Some models are equipped with self diagnostic function, which can automatically detect and report equipment status, helping maintenance personnel to discover and solve problems in a timely manner.
Technical specifications (example)
Detection method: UV or IR detection (depending on the model).
Power requirements: For example, 24V DC, 110V AC, or 220V AC, the specific power requirements depend on the model.
Output signal: usually includes switch output (relay output), analog signal (such as 4-20mA), etc.
Operating temperature range: Generally designed to operate reliably within the range of -20 ° C to+70 ° C.
Response time: Fast response, ensuring timely detection and alarm.
application area
Combustion system:
Used for flame monitoring in equipment such as burners, boilers, heaters, etc., to ensure the stability and safety of the combustion process.
Gas generator:
Applied in gas generators, monitor flame status to prevent equipment damage or shutdown.
Petrochemical and chemical industry:
Monitor flame status in petrochemical and chemical processes to ensure production safety.
Power industry:
Used in combustion equipment in the power industry to ensure safe operation and efficient operation of the equipment.
Installation and maintenance
Installation:
The flame detector should be installed in a position that can effectively monitor the flame, ensuring that there are no obstacles within the detector's line of sight and avoiding direct impact from vibration, dust, or high temperature.
maintain:
Regularly inspect and clean the detection window to prevent dust or dirt from affecting detection performance.
Conduct regular functional testing to ensure the effectiveness and reliability of the equipment during actual operation.
2.产 品 展 示
