YPP110A 3ASD573001A1磁励控制器模块
1.产 品 资 料 介 绍：
中文资料：
YPP110A 3ASD573001A1磁励控制器模块是一款由ABB集团生产的高性能控制器模块，主要应用于电力系统的发电机和发电机组，以及工业自动化和其他需要电动机励磁控制的场景。以下是对其特点和主要功能的详细介绍：
- 产品概述：
- 型号：YPP110A 3ASD573001A1
- 制造商：ABB集团
- 应用领域：电力系统、工业自动化、能源行业、运输领域等
- 主要功能：
- 励磁调节：通过控制励磁电流或电压来调节电动机的磁场强度，确保发电机或其他电动机具有所需的运行特性和性能。
- 励磁保护：能够监测电动机的励磁系统，检测过流、过温等异常情况，并采取适当的保护措施，确保设备和操作人员的安全。
- 励磁调试和诊断：提供调试和诊断功能，帮助工程师检查和优化电动机的励磁系统，确保其正常运行。
- 技术特点：
- 高精度和高响应性能：能够快速准确地控制磁励电流，以适应电力系统的变化和负载需求。
- 可靠性：采用先进的电路设计和可靠的组件，具有良好的抗干扰能力和稳定性，确保在各种工作环境下的可靠运行。
- 多种通信接口：支持多种通信接口，如RS-485、Modbus、CANopen、DeviceNet等，方便与其他设备和系统进行数据交换和控制。
- 编程和配置：可通过软件进行编程和配置，以适应不同的应用需求。用户可以根据具体的发电机和电力系统要求，调整磁励控制参数和设置。
- 安全特性：
- 注重产品安全性，具有多种保护功能和安全机制，可防止过载、过热和其他潜在故障，确保操作人员和设备的安全。
- 产品参数：
- 输入方式：三相交流电源
- 输出：直流电压、直流电流
- 控制方式：V/f、无传感器矢量控制、闭环矢量控制
- 保护功能：过压、欠压、过流、短路、过热
- 输入电压：380 ~ 480vac
- 输出电压：0 ~ 480vdc
- 输出电流：0 ~ 100a
- 频率：50/60Hz
- 功率：75kW
- 应用领域：
- 广泛应用于工业自动化、能源行业、运输领域等，特别是在电力发电厂、变电站、配电系统、电动车辆、铁路和轨道交通系统中。
总之，YPP110A 3ASD573001A1磁励控制器模块凭借其高精度、高可靠性、强大的通信接口和灵活的配置能力，成为工业自动化和电力系统中的重要组成部分。
英文资料
YPP110A 3ASD573001A1 Magnetic Excitation Controller Module is a high-performance controller module produced by ABB Group, mainly used in generators and generator sets in power systems, as well as industrial automation and other scenarios that require motor excitation control. The following is a detailed introduction to its characteristics and main functions:
Product Overview:
Model: YPP110A 3ASD573001A1
Manufacturer: ABB Group
Application areas: power systems, industrial automation, energy industry, transportation, etc
Main functions:
Excitation regulation: By controlling the excitation current or voltage, the magnetic field strength of the motor is adjusted to ensure that the generator or other motor has the required operating characteristics and performance.
Excitation protection: capable of monitoring the excitation system of the motor, detecting abnormal situations such as overcurrent and overheating, and taking appropriate protective measures to ensure the safety of equipment and operators.
Excitation debugging and diagnosis: Provide debugging and diagnostic functions to help engineers inspect and optimize the excitation system of the motor, ensuring its normal operation.
Technical features:
High precision and high response performance: able to quickly and accurately control the excitation current to adapt to changes in the power system and load requirements.
Reliability: Adopting advanced circuit design and reliable components, it has good anti-interference ability and stability, ensuring reliable operation in various working environments.
Multiple communication interfaces: Supports multiple communication interfaces such as RS-485, Modbus, CANopen, DeviceNet, etc., facilitating data exchange and control with other devices and systems.
Programming and configuration: It can be programmed and configured through software to meet different application requirements. Users can adjust the excitation control parameters and settings based on specific generator and power system requirements.
Security features:
Emphasis is placed on product safety, with multiple protective functions and safety mechanisms to prevent overload, overheating, and other potential malfunctions, ensuring the safety of operators and equipment.
Product parameters:
Input method: three-phase AC power supply
Output: DC voltage, DC current
Control methods: V/f, sensorless vector control, closed-loop vector control
Protection functions: overvoltage, undervoltage, overcurrent, short circuit, overheating
Input voltage: 380~480vac
Output voltage: 0~480vdc
Output current: 0~100a
Frequency: 50/60Hz
Power: 75kW
Application field:
Widely used in industrial automation, energy industry, transportation fields, especially in power plants, substations, distribution systems, electric vehicles, railways, and rail transit systems.
In summary, the YPP110A 3ASD573001A1 magnetic excitation controller module has become an important component of industrial automation and power systems due to its high precision, high reliability, powerful communication interfaces, and flexible configuration capabilities.
2.产 品 展 示
3.产 品 展 示
