GE IS220PSVOH1A 伺服接线板 PDF资料
1.产 品 资 料 介 绍：
中文资料：
一、产品简介
GE IS220PSVOH1A 是通用电气（General Electric）公司生产的一款 伺服系统接线板，用于连接和管理伺服驱动器与伺服电机之间的信号和电源线路。该接线板通常应用于 GE Mark VIe、Mark V、PACSystems RX3i 等自动化系统中的运动控制部分，确保伺服系统的高效通信和稳定运行。
二、技术规格
| 项目 | 参数说明 |
|---|---|
| 产品型号 | IS220PSVOH1A |
| 类型 | 伺服接线板（Servo Wiring Board） |
| 功能 | 伺服驱动器与电机间信号及电源接线 |
| 兼容系统 | GE Mark VIe、PACSystems RX3i 等 |
| 接口类型 | 多针连接器，支持编码器、反馈及电源 |
| 安装形式 | 插拔式或螺钉固定 |
| 支持电缆类型 | 屏蔽伺服电缆、编码器信号线 |
| 额定电压 | 24V DC（信号部分）及相应电机电压 |
| 使用环境温度 | 工业环境标准，-20℃ 至 +60℃ |
| 机械尺寸 | 标准工业板卡尺寸，具体尺寸视版本而定 |
三、功能特点
集中接线管理：将伺服驱动器和电机的电源、控制信号、反馈信号统一接入，便于维护和故障排查；
兼容多种编码器信号：支持增量编码器和绝对值编码器接口；
抗干扰设计：采用屏蔽结构与接地措施，保证信号稳定，减少电磁干扰；
模块化结构：便于快速安装与更换，支持现场维护；
高可靠性连接：采用工业级连接器，确保长期稳定运行；
安全保护：具备短路和过载保护接口，防止设备损坏。
英文资料：
Brief introduction
GE IS220PSVOH1A is a servo system wiring board produced by General Electric, used to connect and manage signal and power lines between servo drives and servo motors. This wiring board is commonly used in the motion control section of automation systems such as GE Mark VIe, Mark V, PACSystems RX3i, ensuring efficient communication and stable operation of servo systems.
2、 Technical specifications
Project parameter description
Product model IS220PSVOH1A
Type: Servo Wiring Board
Signal and power wiring between functional servo drive and motor
Compatible with systems such as GE Mark VIe, PACSystems RX3i, etc
Interface type multi pin connector, supporting encoder, feedback, and power supply
Installation form: plug-in or screw fixed
Support cable type shielding servo cable, encoder signal line
Rated voltage 24V DC (signal part) and corresponding motor voltage
Using industrial environmental standards for ambient temperature, ranging from -20 ℃ to+60 ℃
Mechanical size standard industrial board size, specific size depends on the version
3、 Functional Features
Centralized wiring management: Unify the power supply, control signals, and feedback signals of servo drives and motors for easy maintenance and troubleshooting;
Compatible with multiple encoder signals: supports incremental encoder and absolute value encoder interfaces;
Anti interference design: adopting shielding structure and grounding measures to ensure signal stability and reduce electromagnetic interference;
Modular structure: easy to install and replace quickly, supports on-site maintenance;
High reliability connection: using industrial grade connectors to ensure long-term stable operation;
Safety protection: Equipped with short-circuit and overload protection interfaces to prevent equipment damage.
2.产 品 展 示
