ABB SA167 3BSE003390R1电源装置
展开位置Y4的驱动器类型组，选择位置Y4中的754-1驱动器C选项3。展开位置X4的驱动类型组，选择位置X4中的755-1驱动C选项此选项为定位器轴添加驱动模块。注意！使用最新的驱动系统时，请执行以下操作：向下滚动至DriveModule1>驱动模块配置组；选择“驱动系统09 120/140/1400/1600紧凑型”选项；展开“电源配置”组，然后选择“单相电源”或“三相电源”（如适用）>“附加轴驱动模块”>“附加驱动1”。展开位置X3中的驱动类型组，选择位置X3中驱动ADU-790A选项2。展开位置Y3的驱动器类型组，选择位置Y3中的驱动器ADU-790A选项
Expand the Drive type in position Y4 group and select the754-1 Drive C in pos Y4
option
3. Expand the Drive type in position X4 group and select the755-1 Drive C in pos X4
option
This option adds drive modules for the positioner axes.
NOTE!
When using the latest drive system, do the following:
Scroll down to the DriveModule1 > Drive module configuration group; select the Drive
System 09 120/140/1400/1600 Compact option; expand the Power supply
configuration group and select 1-Phase Power supply or 3-Phase Power supply (as
applicable) > Additional axes drive module > Additional drive
1. Expand the Drive type in position X3 group and select the Drive ADU-790A in
position X3 option
2. Expand the Drive type in position Y3 group and select the Drive ADU-790A in
position Y3 option
