IS200TRLYH1BGF继电器端子板

1.产 品 资 料 介 绍：

中文资料：

IS200TRLYH1BGF继电器端子板是GE公司生产的一款产品，它主要用于Mark VI汽轮机控制系统中的终端继电器卡。以下是关于该产品的详细特点描述：

1. 设计特点：
• 继电器连接：该端子板配备有继电器插槽，用于连接和控制继电器。继电器是一种电子开关设备，用于在电路中控制电流的流动。
• 输入和输出：该端子板具有输入和输出连接点，用于将信号传输到继电器并从继电器中接收信号。这些输入和输出可以与其他设备和系统连接，以实现控制和监测。
• 电路保护：一些终端板可能具有电路保护功能，以防止电流过载或其他电气问题。
2. 物理描述：
• 端子数量：IS200TRLYH1BGF在其左边缘包含两个大型黑色端子板，每个接线板都有24个银色金属端子，总共48个终端。每一个端子都用白字标在端子板上。
• 连接器端口：该板在右边界有四个连接器端口，其中三个连接器端口在边缘垂直对齐，最后一个与底部的连接器端口平行。
• 继电器排列：在IS200TRLYH1BGF的中心附近有一长串继电器，它们是白色和黑色的，带有形状像立方体的透明盖子。这些元件用黑线连接到PCB上。其中，五个继电器垂直排列在板的上半部分，另外五个继电器排列在PCB的下半部分。
• 其他元件：每个继电器的两侧是一个黑色的圆形晶体管。与每个晶体管配对的是一个圆形的红色MOV或金属氧化物变阻器。
3. 功能特点：
• 表决线圈驱动反馈：该端子板可能具备表决线圈驱动反馈功能，确保继电器动作的准确性和可靠性。
• MOV抑制：金属氧化物变阻器（MOV）的引入可能用于限制电压瞬变和浪涌，以保护电路和继电器免受损坏。
4. 诊断和监测：
• 该产品可能具有先进的诊断和监测功能，如继电器输出（线圈电流）的监控、电磁阀励磁电压的监测、继电器触点电压的监测等，以确保系统的正常运行和故障预警。

英文资料

IS200TRLYH1BGF relay terminal board is a product produced by GE, mainly used for terminal relay cards in Mark VI turbine control systems. The following is a detailed description of the product's features:

Design features:

Relay connection: This terminal board is equipped with relay slots for connecting and controlling relays. A relay is an electronic switching device used to control the flow of current in a circuit.

Input and Output: This terminal board has input and output connection points for transmitting signals to and receiving signals from relays. These inputs and outputs can be connected to other devices and systems for control and monitoring.

Circuit protection: Some terminal boards may have circuit protection functions to prevent current overload or other electrical problems.

Physical description:

Terminal quantity: IS200TRLYH1BGF contains two large black terminal blocks on its left edge, each with 24 silver metal terminals, for a total of 48 terminals. Each terminal is marked with white letters on the terminal board.

Connector Ports: The board has four connector ports on the right boundary, with three connector ports aligned vertically at the edges and the last parallel to the bottom connector port.

Relay arrangement: There is a long string of relays near the center of IS200TRLYH1BGF, which are white and black with transparent covers shaped like cubes. These components are connected to the PCB with black wires. Among them, five relays are arranged vertically in the upper half of the board, and the other five relays are arranged in the lower half of the PCB.

Other components: There are black circular transistors on both sides of each relay. Paired with each transistor is a circular red MOV or metal oxide varistor.

Functional features:

Voting coil drive feedback: This terminal board may have voting coil drive feedback function to ensure the accuracy and reliability of relay action.

MOV suppression: The introduction of metal oxide varistors (MOVs) may be used to limit voltage transients and surges to protect circuits and relays from damage.

Diagnosis and monitoring:

This product may have advanced diagnostic and monitoring functions, such as monitoring relay output (coil current), electromagnetic valve excitation voltage, relay contact voltage, etc., to ensure the normal operation of the system and fault warning.
