ABB 3bhb030310r0001电网断路器单元 PDF资料

1.产 品 资 料 介 绍：

中文资料：

ABB 3BHB030310R0001 是一款用于中高压驱动系统中的电网断路器控制单元（Grid Breaker Unit）。它主要用于管理电源与驱动设备之间的电气连接，通过控制断路器的合闸与分闸，实现系统启动、运行及故障保护时的电网隔离。该产品广泛集成于 ABB 的中压变频器系统（如 ACS6000）中，是整个驱动系统电源控制与保护的重要组成部分。

技术参数（简要）

• 型号：3BHB030310R0001

• 功能类型：电网断路控制，驱动系统电源管理

• 控制电压：典型为 24V DC（具体取决于配套系统）

• 支持通信：与 ABB 控制板（如 PMI、GVC 等）连接，具备状态反馈功能

• 系统适配：常见于 ABB ACS5000、ACS6000 系列变频器系统

• 安装方式：模块化设计，可集成于机柜或变频系统内部

• 适用电压等级：6kV / 11kV 中压系统（视整机配置）

应用领域

1. 中压变频器系统电源管理

• 作为电网输入侧控制装置，控制电源接入或切断，保护变频器系统的稳定运行。

• 适配 ABB ACS6000、ACS5000 等高压变频设备。

2. 大型工业驱动系统

• 用于矿山、冶金、水泥、电厂等行业的高功率电机控制场合。

• 实现主电源的远程控制与异常断开保护。

3. 自动化配电与能源管理系统

• 应用于高压供电系统，实现远程断路、母线切换等自动控制功能。

4. 风电与水处理等连续运行系统

• 用于风力发电、水泵系统中关键电源控制节点，提升系统可靠性与维护效率。

产品优势

• 快速响应：可在毫秒级别内控制电源断开，避免系统过载或损坏

• 高安全性：具备短路、过压等保护能力，支持与系统故障检测模块联动

• 系统兼容性强：与 ABB 多种控制模块（如 PMI、SDCS、PEC）无缝协同

• 便于维护：模块化设计，故障定位快捷，支持快速更换与现场调试

• 适用于恶劣环境：工业级设计标准，支持高温、强干扰等复杂电气环境运行

英文资料：

ABB 3BHB030310R0001 is a grid breaker control unit used in medium and high voltage drive systems. It is mainly used to manage the electrical connection between power supply and driving equipment, and to achieve grid isolation during system startup, operation, and fault protection by controlling the closing and opening of circuit breakers. This product is widely integrated into ABB's medium voltage frequency converter system (such as ACS6000) and is an important component of the power control and protection of the entire drive system.

Technical parameters (brief)

Model: 3BHB030310R0001

Function type: Power grid circuit breaker control, drive system power management

Control voltage: Typically 24V DC (depending on the supporting system)

Support communication: connected to ABB control boards (such as PMI, GVC, etc.), with status feedback function

System adaptation: commonly used in ABB ACS5000 and ACS6000 series frequency converter systems

Installation method: Modular design, can be integrated into cabinets or frequency conversion systems

Applicable voltage level: 6kV/11kV medium voltage system (depending on the overall configuration)

application area

Power Management of Medium Voltage Inverter System

As an input side control device of the power grid, it controls the connection or disconnection of the power supply to protect the stable operation of the frequency converter system.

Suitable for ABB ACS6000, ACS5000 and other high-voltage frequency conversion equipment.

Large industrial drive system

Used for high-power motor control in industries such as mining, metallurgy, cement, and power plants.

Implement remote control and abnormal disconnection protection for the main power supply.

Automated Distribution and Energy Management System

Applied to high-voltage power supply systems, it achieves automatic control functions such as remote circuit breaking and bus switching.

Continuous operation systems such as wind power and water treatment

Used as a key power control node in wind power generation and water pump systems to enhance system reliability and maintenance efficiency.

Product advantages

Quick response: can control power disconnection within milliseconds to avoid system overload or damage

High security: equipped with protection capabilities such as short circuit and overvoltage, supporting linkage with system fault detection modules

Strong system compatibility: seamless collaboration with multiple ABB control modules (such as PMI, SDCS, PEC)

Easy to maintain: modular design, quick fault location, support for quick replacement and on-site debugging

Suitable for harsh environments: Industrial grade design standards, supporting operation in complex electrical environments such as high temperatures and strong interference
