IC660BBD022数字量模块
1.产 品 资 料 介 绍：
中文资料：
IC660BBD022数字量模块是一款由GE Fanuc生产的Genius I/O Block系列中的16电路源I/O模块。以下是关于该模块的详细信息和特点：
- 概述：
- IC660BBD022是一个支持Genius协议的模块，作为独立的单节点I/O站，它提供了十六（16）个I/O电路，支持源接线配置。
- 技术参数：
- 工作电压：24 / 48 VDC，使其能适应多种电压需求。
- 输入输出配置：模块的每个通道都可以独立配置为输入或输出，具有高度的灵活性。
- 数据交换：通过Genius I/O总线端子，IC660BBD022可以与GE的可编程逻辑和自动化控制器（PLC/PAC）、总线控制器、PC接口模块、人机界面（HMI）等模块以及第三方设备进行数据交换。
- 设计特点：
- 安装方式：该模块是面板安装的独立设备，具有开放式外壳，需安装在外壳内，以保护其免受工业污染物的损害。
- 远程安装：IC660BBD022支持远程安装，与伙伴设备的最大距离可达7500英尺。
- 菊花链连接：它支持菊花链连接其他I/O模块，形成Genius I/O网络，增强了系统的扩展性和灵活性。
- 配置与诊断：
- 配置方式：IC660BBD022支持两种配置方式：本地配置和远程配置。本地配置可以通过安装在终端组件顶部的HHM端口，使用手持监视器（HHM）进行；远程配置则可以使用主控制器的编程软件进行。
- 诊断功能：该模块具有诊断功能和安全措施，能够轻松检测过载、过热、短路、空载和开关故障等错误，并通过I/O启用和单元确定LED灯提醒操作员注意。
- 物理特性：
- 尺寸：IC660BBD022的尺寸为高8.83英寸、深4.42英寸、宽3.56英寸，体积小巧，节省面板空间。
- 电源与负载：它使用24伏直流电源，负载电流为2安培，可以与2线制和3线制传感器一起使用。
- 其他功能：
- 可配置功能：包括输出功率默认值、可选输入滤波时间和输出脉冲测试功能，为用户提供更多的选择和灵活性。
- 兼容性：IC660BBD022可以轻松地与GE的其他产品集成，为用户提供全面的自动化解决方案。
总的来说，IC660BBD022数字量模块是一款功能强大、配置灵活、易于安装和维护的数字量I/O模块，适用于各种工业自动化和控制应用。
英文资料
The IC660BBD022 digital quantity module is a 16 circuit source I/O module in the Genius I/O Block series produced by GE Fanuc. The following is detailed information and features about this module:
summary:
IC660BBD022 is a module that supports the Genius protocol. As an independent single node I/O station, it provides sixteen (16) I/O circuits and supports source wiring configuration.
Technical parameters:
Working voltage: 24/48 VDC, allowing it to adapt to various voltage requirements.
Input/output configuration: Each channel of the module can be independently configured as input or output, with a high degree of flexibility.
Data exchange: Through Genius I/O bus terminals, IC660BBD022 can exchange data with GE's programmable logic and automation controllers (PLC/PAC), bus controllers, PC interface modules, human-machine interface (HMI) modules, and third-party devices.
Design features:
Installation method: This module is a panel mounted independent device with an open casing that needs to be installed inside the casing to protect it from industrial pollutants.
Remote installation: IC660BBD022 supports remote installation, with a maximum distance of 7500 feet from partner devices.
Daisy chain connection: It supports daisy chain connection to other I/O modules, forming a Genius I/O network, enhancing system scalability and flexibility.
Configuration and Diagnosis:
Configuration method: IC660BBD022 supports two configuration methods: local configuration and remote configuration. Local configuration can be achieved through the HHM port installed at the top of the terminal component, using a handheld monitor (HHM); Remote configuration can be done using the programming software of the main controller.
Diagnostic function: This module has diagnostic function and safety measures, which can easily detect errors such as overload, overheating, short circuit, no-load, and switch faults, and remind operators to pay attention through I/O activation and unit determination LED lights.
Physical properties:
Dimensions: The dimensions of IC660BBD022 are 8.83 inches high, 4.42 inches deep, and 3.56 inches wide. It is compact and saves panel space.
Power and load: It uses a 24 volt DC power supply with a load current of 2 amperes and can be used with 2-wire and 3-wire sensors.
Other features:
Configurable features: including default output power value, optional input filtering time, and output pulse testing function, providing users with more choices and flexibility.
Compatibility: IC660BBD022 can easily integrate with other GE products, providing users with comprehensive automation solutions.
Overall, the IC660BBD022 digital quantity module is a powerful, flexible, easy to install and maintain digital quantity I/O module, suitable for various industrial automation and control applications.
2.产 品 展 示
3.产 品 展 示
