SHINKO SBX93-100097-1通讯模块 PDF资料
1.产 品 资 料 介 绍：
SHINKO SBX93-100097-1 通讯模块，以下为主要特点。
属于日本神港（SHINKO TECHNOS）品牌的通讯模块产品。
主要用于PLC与外围设备之间的通信中介。
支持SHINKO协议和MODBUS协议（ASCII模式、RTU模式）。
最多可连接95台支持SHINKO协议或MODBUS协议的通信设备。
提供四种通信方式：固定地址、灵活地址、多地址和无标志方法。
固定地址方式下最多可连接20台设备。
采用插入式插座设计，无需拆除接线即可装卸主体。
与PLC之间支持RS-232C、RS-485、RS-422A等多种通信线路。
与控制器之间采用RS-485通信线路。
通信速度支持9600 bps、19200 bps、38400 bps。
数据格式可设：数据长度7/8位、校验位无/偶/奇、停止位1/2位。
可适配三菱MELSEC、欧姆龙SYSMAC、基恩士KV、横河FA-M3等多种品牌PLC。
通过PLC寄存器进行数据读写操作，完成数据交换。
支持通过USB连接PC进行参数设置和配置。
适用于温度控制、过程控制等工业自动化系统。
结尾
综上，SHINKO SBX93-100097-1在协议兼容性、连接数量、通信方式和维护便捷性等方面配置明确，是一款适用于工业自动化系统通信连接的实用模块。
SHINKO SBX93-100097-1通讯模块 英文介绍
The main features of the SHINKO SBX93-100097-1 communication module are as follows.
A communication module product belonging to the SHINKO TECHNOS brand in Japan.
Mainly used as a communication intermediary between PLC and peripheral devices.
Supports SHINKO protocol and MODBUS protocol (ASCII mode, RTU mode).
Up to 95 communication devices that support SHINKO protocol or MODBUS protocol can be connected.
Provide four communication methods: fixed address, flexible address, multi address, and unmarked method.
Under fixed address mode, up to 20 devices can be connected.
Adopting a plug-in socket design, the main body can be installed and removed without dismantling the wiring.
Supports various communication lines such as RS-232C, RS-485, RS-422A, etc. between PLC.
RS-485 communication line is used between the controller and the controller.
The communication speed supports 9600 bps, 19200 bps, and 38400 bps.
The data format can be set as follows: data length of 7/8 bits, parity bits of no/even/odd, and stop bits of 1/2 bits.
It can be adapted to various brands of PLCs such as Mitsubishi MELSEC, Omron SYSMAC, Keyence KV, Yokogawa FA-M3, etc.
Perform data read and write operations through PLC registers to complete data exchange.
Support parameter setting and configuration through USB connection to PC.
Suitable for industrial automation systems such as temperature control and process control.
ending
Overall, SHINKO SBX93-100097-1 has clear configurations in terms of protocol compatibility, connection quantity, communication method, and maintenance convenience, making it a practical module suitable for communication connections in industrial automation systems.
SHINKO SBX93-100097-1通讯模块 产品展示
