设定最大模拟输出（20 mA或10V）将最大模拟输出表示的对象放置在阵列内。按下并松开示教按钮。现在，状态指示器D15每3秒闪烁三次，表示已识别到任何中断的光束。如果没有光束中断，运行模式下的最大模拟输出值（20 mA或10V）表示没有光束中断。4.完成示教要完成示教过程，请按住示教按钮，直到状态指示器D15熄灭（约5秒），这表示示教过程结束。设定值保存到非易失性（闪存）存储器中。或者，短按设定按钮可以丢弃新设定的值。状态指示器D15关闭（表示示教过程结束），恢复先前的值。示教过程注意事项：•如果控制器设置为绝对/位置模式（DIP开关S1:2=OFF），则仅当示教区域内的光束中断时，离散输出（Out 1）才会改变状态。例如，如果为射束10设置最小模拟输出，为射束30设置最大模拟输出，则仅阻挡射束5或射束40不会改变离散输出的状态，而中断射束20会改变离散输出状态。如果光束40和光束20都被阻挡，则离散输出改变状态。如果控制器设置为相对/尺寸模式（DIP开关S1:2=ON），如果任何光束中断，离散输出（Out 1）将改变状态。•代替在示教过程中使用要检测的实际物体，可以在示教期间通过其他手段（例如金属标志）中断适当的光束。表7-J15引脚列表引脚信号最小值最大值1 I输出4 mA 20 mA 2 0V DC 3 V输出0V 10V 4 0V DC表8-模拟板状态指示器状态指示器描述状态含义D15示教指示器关闭示教不活动闪烁示教活动橙色示教过程的最后一步D16模拟输出状态关闭V_Out=Off（0V）闪烁启动（忽略输出），过电流，或错误绿色亮度与模拟输出成比例重要信息一旦更改，DIP开关设置仅在电源循环后才能识别。
Teach maximum analog output (20 mA or 10V) Place the object that is to be represented by the maximum analog output within the arrays. Press and release the teach button. Status indicator D15 now flashes three times every 3 seconds, which indicates that any interrupted beams have been recognized. If no beams are interrupted, the maximum analog output value (20 mA or 10V) in Run mode indicates that no beams are interrupted. 4. Complete teach To complete the teach process, press and hold the Teach button until the status indicator D15 turns off (approximately 5 seconds), which signals the end of the teach process. The taught values are saved to non-volatile (flash) memory. Alternatively, briefly pressing the Teach button can discard the newly taught values. Status indicator D15 turns off (which indicates the end of the teach process) and the previous values are restored. Notes on the teach process: • If the controller is set in absolute/position mode (DIP switch S1:2 = OFF), the discrete output (Out 1) changes state only when a beam within the taught area is interrupted. For example, if the minimum analog output is set for beam 10 and the maximum analog output is set for beam 30, blocking only beam 5 or beam 40 does not change the state of the discrete output, while interrupting beam 20 would change the state of the discrete output. The discrete output changes state if both beam 40 AND beam 20 are blocked. If the controller is set in relative/size mode (DIP switch S1:2 = ON), the discrete output (Out 1) changes state if any beam is interrupted. • Instead of using the actual object to be detected for the teach process, the appropriate beams may be interrupted by other means during the teach process, such as a metal flag. Table 7 - J15 Pin Listings Pin Signal Minimum Maximum 1 I Out 4 mA 20 mA 2 0V DC 3 V Out 0V 10V 4 0V DC Table 8 - Analog Board Status Indicators Status Indicator Description Status Meaning D15 Teach Indicator Off Teach inactive Flashing Teach active Orange Last step of teach process D16 Analog Output Status Off V_out = OFF (0V) Flashing Start up (ignore output), over current, or error Green Brightness proportional to analog output IMPORTANT Once changed, DIP switch settings are only recognized after a power cycle.
