ABB REU615E-D控制继电器
DP-V1主机的状态处理状态处理CI854/CI854A的硬件和软件错误的每个状态信息都通过设备状态指示。当CBM处于在线模式时，单元状态用于在Control Builder M中显示HW单元的状态。此外，根据装置状态生成报警/事件（请参阅第36页的报警和事件）。出于特殊原因，还支持通过控制器应用程序访问装置状态。下表显示了为CI854/CI854A DeviceSpecific10 Reserved 23 16#008000 0 CI854（A）上的硬件看门狗已过期错误报警介质主CI854/CIL854A上的硬件监视器未被CI854/C1854A触发固件超时。24 16#00100000 0 PROFIBUS主配置错误报警介质中的错误在主单元上检测到配置错误。
Status Handling
Status Handling for DP-V1 Master Unit
Every status information for CI854/CI854A in terms of hardware and software
errors is indicated via the unit status. The unit status is used to present the status of
the HW unit in Control Builder M while CBM is in online mode. In addition
alarms/events are generated based on the unit status (please refer also to Alarms and
Events on page 36). For special reasons also the access to the unit status via the
controller application is supported.The both following tables present all device specific ErrorsAndWarnings and
ExtendedStatus defined for CI854/CI854A DeviceSpecific10 Reserved
23 16#0080000
0
Hardware
watchdog on
CI854(A) expired
Error Alarm Mediu
m
The HW watchdog on the primary
CI854/CI854A was not triggered
by the CI854/CI854A firmware
within the timeout.
24 16#0100000
0
Error in
PROFIBUS
master
configuration
Error Alarm Mediu
m
A configuration error has been
detected on the primary unit.
