Agilent 0190-A3401双泵控制器 PDF资料
1.产 品 资 料 介 绍：
Agilent 0190-A3401 双泵控制器，以下为主要特点。
属于安捷伦4UHV系列离子泵控制器。
设计用于独立控制和监测两台离子泵。
支持二极、改进型二极、三极、StarCell等多种离子泵类型。
输出开路电压可选3kV、5kV或7kV。
支持本地、串行和远程三种操作模式。
前面板配备4行20字符LCD显示屏，可同时显示压力、电流和状态。
电流测量范围10nA至100mA，覆盖从粗真空到极高真空。
具备STEP模式，可根据压力自动调节高压以获得最佳抽速。
具备IProtect过流保护功能，气压异常时自动关闭高压输出。
配备高压联锁系统，拔出高压插头时立即切断输出。
内置设定值输出、远程I/O及RS232/485通信接口。
可选配以太网和Profibus通信模块。
可为非安捷伦离子泵提供可编程输出配置。
工作温度0°C至40°C，湿度最大90%无冷凝。
符合CE第3版EMC标准要求。
结尾
综上，Agilent 0190-A3401在双泵独立控制、多种操作模式和安全保护等方面功能明确，是一款适用于超高真空系统的离子泵控制器。
The Agilent 0190-A3401 dual pump controller has the following main features.
Belongs to the Agilent 4UHV series ion pump controller.
Designed for independent control and monitoring of two ion pumps.
Supports multiple types of ion pumps such as bipolar, improved bipolar, tri polar, StarCell, etc.
The output open circuit voltage can be selected from 3kV, 5kV, or 7kV.
Supports three operation modes: local, serial, and remote.
The front panel is equipped with a 4-row 20 character LCD display screen, which can simultaneously display pressure, current, and status.
The current measurement range is 10nA to 100mA, covering from coarse vacuum to extremely high vacuum.
Equipped with STEP mode, it can automatically adjust high pressure according to pressure to achieve optimal pumping speed.
Equipped with the FHIR otect overcurrent protection function, it automatically shuts off the high voltage output when the air pressure is abnormal.
Equipped with a high-voltage interlocking system, the output is immediately cut off when the high-voltage plug is unplugged.
Built in set value output, remote I/O, and RS232/485 communication interface.
Optional Ethernet and Profibus communication modules.
Can provide programmable output configuration for non Agilent ion pumps.
The working temperature ranges from 0 ° C to 40 ° C, with a maximum humidity of 90% and no condensation.
Compliant with CE 3rd edition EMC standard requirements.
ending
Overall, Agilent 0190-A3401 has clear functions in dual pump independent control, multiple operating modes, and safety protection, making it an ion pump controller suitable for ultra-high vacuum systems.
