AMAT 0100-1200印刷电路板 PDF资料
1.产 品 资 料 介 绍：
AMAT 0100-1200 印刷电路板，以下为主要特点。
属于美国应用材料（AMAT）半导体设备专用PCB。
用于刻蚀、沉积等半导体制程设备。
采用罗杰斯RO1200高频材料。
介电常数约3.05，适合高频信号传输。
损耗因子0.0017，信号损耗较低。
热膨胀系数8 ppm/°C，与铜匹配良好。
导热系数0.42 W/mK，散热性能较好。
热分解温度500°C，耐高温性能优异。
吸水率仅0.03%，尺寸稳定性好。
阻燃等级UL 94 V-0，符合安规要求。
兼容无铅工艺，满足环保标准。
适用于高频、高速信号传输场景。
支持定制厚度、尺寸和铜箔规格。
常见于AMAT 200mm及300mm设备。
具备良好的抗干扰和信号完整性。
结尾
综上，AMAT 0100-1200在材料性能、信号完整性和耐高温等方面配置明确，是一款适用于半导体设备的高频PCB。
AMAT 0100-1200印刷电路板 英文介绍
AMAT 0100-1200 printed circuit board, the following are the main features.
Belongs to the American Applied Materials (AMAT) semiconductor equipment dedicated PCB.
Used for semiconductor process equipment such as etching and deposition.
Using Rogers RO1200 high-frequency material.
The dielectric constant is about 3.05, suitable for high-frequency signal transmission.
The loss factor is 0.0017, indicating low signal loss.
The coefficient of thermal expansion is 8 ppm/° C, which matches well with copper.
The thermal conductivity is 0.42 W/mK, and the heat dissipation performance is good.
The thermal decomposition temperature is 500 ° C, and the high temperature resistance is excellent.
The water absorption rate is only 0.03%, and the dimensional stability is good.
Flame retardant rating UL 94 V-0, in compliance with safety regulations.
Compatible with lead-free technology and meets environmental standards.
Suitable for high-frequency and high-speed signal transmission scenarios.
Support customized thickness, size, and copper foil specifications.
Commonly seen in AMAT 200mm and 300mm equipment.
Has good anti-interference and signal integrity.
ending
Overall, AMAT 0100-1200 has clear configurations in terms of material properties, signal integrity, and high temperature resistance, making it a high-frequency PCB suitable for semiconductor equipment.
AMAT 0100-1200印刷电路板 产品展示
