Daihen AMN-50E6-V射频匹配模块 PDF资料
1.产 品 资 料 介 绍：
Daihen AMN-50E6-V 是日本大亨（Daihen）公司生产的一款射频自动匹配模块。
专为半导体等离子体工艺设备设计，用于射频传输系统的阻抗匹配。
支持50Ω射频传输系统标准，适配主流射频电源。
采用高速电机驱动真空可变电容，响应速度快。
具备自动调谐功能，可实时跟踪负载阻抗变化。
匹配速度快，可有效降低反射功率，提高射频传输效率。
工作频率范围通常为13.56MHz及倍频，兼容主流工艺频率。
模块化结构设计，便于在设备机台上安装与维护。
采用水冷或风冷散热设计，确保连续运行时的热稳定性。
内置射频电压、电流、相位及功率检测传感器。
具备I/O接口或通信接口，便于与上位机集成控制。
采用高可靠性工业级元器件，适应苛刻的工艺环境。
常见于刻蚀、沉积等等离子体工艺设备。
作为原厂配件，与Daihen匹配器系列兼容性良好。
市场上备件供应与维修服务渠道相对成熟。
结尾： 综上，Daihen AMN-50E6-V 凭借高速自动匹配、精准的射频监测和可靠的散热设计，是等离子体工艺设备中保障射频功率高效传输的关键组件。
Daihen AMN-50E6-V is an RF automatic matching module produced by Daihen Corporation in Japan.
Specially designed for semiconductor plasma process equipment, used for impedance matching in RF transmission systems.
Supports 50 Ω RF transmission system standard and is compatible with mainstream RF power supplies.
Adopting high-speed motor to drive vacuum variable capacitor, with fast response speed.
Equipped with automatic tuning function, it can track real-time changes in load impedance.
Fast matching speed can effectively reduce reflected power and improve RF transmission efficiency.
The working frequency range is usually 13.56MHz and multiples, compatible with mainstream process frequencies.
Modular structural design facilitates installation and maintenance on equipment and machinery.
Adopting water-cooled or air-cooled heat dissipation design to ensure thermal stability during continuous operation.
Built in RF voltage, current, phase, and power detection sensors.
Equipped with I/O interface or communication interface, it is easy to integrate and control with the upper computer.
Adopting high reliability industrial grade components to adapt to harsh process environments.
Commonly used in plasma process equipment such as etching and deposition.
As an original accessory, it has good compatibility with the Daihen matching series.
The supply and maintenance service channels for spare parts in the market are relatively mature.
Conclusion: In summary, Daihen AMN-50E6-V is a key component in plasma process equipment that ensures efficient transmission of RF power, thanks to its high-speed automatic matching, precise RF monitoring, and reliable heat dissipation design.
