Nikon S9037-0902N图像传感器 PDF资料
1.产 品 资 料 介 绍：
Nikon S9037-0902N 图像传感器是一款专为高速线扫描应用设计的图像传感组件，以下是其主要产品特点。
中间
完整产品型号为 S9037-0902N。
属于面阵CCD图像传感器类别。
采用背面入射结构。
在紫外区域具有极高的灵敏度。
有效像素数为 512 × 4。
像素尺寸为 24μm × 24μm。
有效感光区域为 12.288mm × 0.096mm。
数据速率为 10MHz。
最大线扫描速率可达 16kHz。
非制冷型设计。
采用金属封装结构。
具备行与像素合并功能。
具备高信噪比输出特性。
适用于高速紫外成像场景。
适用于半导体检查设备。
总结
Nikon S9037-0902N 图像传感器以高紫外灵敏度、高速扫描和背面入射结构为核心，适用于半导体光刻、光谱分析及高速紫外成像等专业场景。
The Nikon S9037-0902N image sensor is an image sensing component designed specifically for high-speed line scanning applications. The following are its main product features.
middle
The complete product model is S9037-0902N.
Belongs to the category of area array CCD image sensors.
Adopting a backside incident structure.
Has extremely high sensitivity in the ultraviolet region.
The effective pixel count is 512 × 4.
The pixel size is 24 μ m × 24 μ m.
The effective photosensitive area is 12.288mm × 0.096mm.
The data rate is 10MHz.
The maximum line scanning rate can reach 16kHz.
Non refrigerated design.
Adopting a metal encapsulation structure.
Capable of merging rows and pixels.
Has high signal-to-noise ratio output characteristics.
Suitable for high-speed ultraviolet imaging scenes.
Suitable for semiconductor inspection equipment.
summary
The Nikon S9037-0902N image sensor features high UV sensitivity, high-speed scanning, and backside incident structure as its core, making it suitable for professional scenarios such as semiconductor lithography, spectral analysis, and high-speed UV imaging.
