ISEL IPA-38-VVS3-1 自动化控制系统 PDF资料
1.产 品 资 料 介 绍：
ISEL IPA-38-VVS3-1 自动化控制系统产品特点
- 控制驱动电源一体化，无需额外搭配驱动电源
- 内置 32K 断电保存存储，程序掉电不丢失
- 4 路隔离输入、4 路继电器输出，可对接各类传感器
- RS232 双向串口通讯，最高 19200bps 传输速率
- 面板 LED 指示灯，运行故障状态直观查看
- 支持独立离线运行、电脑联机两种控制模式
- 微步细分驱动，电机运行低噪音无共振
- 44V/3.5A 峰值输出，适配两相步进电机
- 拨码可调电机电流与细分参数，调试便捷
- 短路、过压、欠压、过热多重故障保护
- 支持寸动、示教、批量程序自动运行功能
- 自带电机抱闸控制回路，断电锁止稳定
- 直线插补运动，定位速度快、重复精度高
- 标准端子接线，拆装布线简单易维护
- 紧凑型箱体，桌面 / 机柜安装均可，占用空间小结尾：ISEL IPA-38-VVS3-1 集成度高、调试简易、防护全面，是小型精密自动化工位专用运动控制成套设备。
ISEL IPA-38-VVS3-1 自动化控制系统 英文介绍
ISEL IPA-38-VVS3-1 Automation Control System Product Features
Introduction: ISEL IPA-38-VVS3-1 is a single axis integrated motion control system that integrates drive, power, and control units, suitable for small automated displacement equipment.
Integrated control of driving power supply, no need for additional matching of driving power supply
Built in 32K power-off storage, program will not be lost in case of power failure
4-channel isolated input, 4-channel relay output, can be connected to various sensors
RS232 bidirectional serial communication, with a maximum transmission rate of 19200bps
Panel LED indicator light for intuitive viewing of operational fault status
Supports two control modes: independent offline operation and computer online operation
Microstep subdivision drive, low noise and resonance free motor operation
44V/3.5A peak output, compatible with two-phase stepper motors
Dial code adjustable motor current and subdivision parameters, easy to debug
Multiple fault protection for short circuit, overvoltage, undervoltage, and overheating
Support automatic running functions for inch movement, teaching demonstration, and batch programs
Equipped with a built-in motor brake control circuit, stable locking in case of power failure
Linear interpolation motion, fast positioning speed, high repeatability accuracy
Standard terminal wiring, easy to disassemble and maintain wiring
Compact enclosure, suitable for desktop/cabinet installation, occupying minimal space
Conclusion: ISEL IPA-38-VVS3-1 has high integration, easy debugging, and comprehensive protection, making it a complete set of small precision automation workstation specific motion control equipment.
ISEL IPA-38-VVS3-1 自动化控制系统 产品展示
