ZYGO 8070-0902-13X激光器 PDF资料
1.产 品 资 料 介 绍：
ZYGO 8070-0902-13X激光器产品特点
ZYGO 8070-0902-13X是一款高性能氦氖激光器，专为精密位移测量设计，其核心特点如下：
连续波、外差式、线偏振氦氖激光源。
输出功率大于250μW。
适配ZYGO ZMI 501/501A型电子设备。
光束直径4.1±0.3mm，指向稳定性0.2mrad。
固定频率差3.6±0.3MHz。
真空波长632.992nm，终身精度±0.2ppm。
短期稳定性0.01ppm/小时，长期0.02ppm/24小时。
出光<30秒，波长稳定≤15分钟。
供电+15V DC，工作功耗7W，预热9W。
重1.0kg，铝合金+ABS材质。
工作温度10~30℃，湿度0~90%（无凝结）。
储存温度-40~75℃。
抗冲击40g（11ms）。
符合DHHS激光安全标准。
适用于半导体制造、精密工程等计量领域。
总体而言，ZYGO 8070-0902-13X以稳定的激光输出、高波长精度和可靠的环境适应性，为精密工业测量提供了理想的解决方案。
ZYGO 8070-0902-13X Laser Product Features
ZYGO 8070-0902-13X is a high-performance helium neon laser designed specifically for precision displacement measurement. Its core features are as follows:
Continuous wave, heterodyne, linearly polarized helium neon laser source.
The output power is greater than 250 μ W.
Compatible with ZYGO ZMI 501/501A electronic devices.
The beam diameter is 4.1 ± 0.3mm and the directional stability is 0.2mrad.
Fixed frequency difference of 3.6 ± 0.3MHz.
Vacuum wavelength 632.992nm, lifetime accuracy ± 0.2ppm.
Short term stability of 0.01 ppm/hour, long-term stability of 0.02 ppm/24 hours.
Light output<30 seconds, wavelength stability ≤ 15 minutes.
Power supply+15V DC, working power consumption 7W, preheating 9W.
Weighing 1.0kg, made of aluminum alloy and ABS material.
The working temperature is 10-30 ℃, and the humidity is 0-90% (without condensation).
Storage temperature -40~75 ℃.
Resistance to impact 40g (11ms).
Compliant with DHHS laser safety standards.
Suitable for metrology fields such as semiconductor manufacturing and precision engineering.
Overall, ZYGO 8070-0902-13X provides an ideal solution for precision industrial measurement with stable laser output, high wavelength accuracy, and reliable environmental adaptability.
