ADAS ICV307 隔离信号采集板 PDF资料

1.产 品 资 料 介 绍：

ADAS ICV307 隔离信号采集板产品特点：

支持6路独立32位计数通道

每通道配备A、B、选通、清除四路输入

支持+5V、+12V、+15V、+24V多种输入电平

内置滤波电路，适应干扰环境

可直接连接增量式编码器

支持X1和X4计数模式

隔离输入耐压高达2500V

输入电流低，约6mA

高速计数最高支持5MHz

具备2种时基和1路可编程时钟

多种工作模式可通过VME总线编程

支持26个可编程中断源

兼容VME ANSI/IEEE 1014标准

与ICV 306硬件软件全兼容

适用于工业计数与信号采集场景

总结：ADAS ICV307 隔离信号采集板以6路高速32位计数通道、最高2500V隔离耐压和多种输入电平兼容为核心特点，适用于编码器计数及工业信号采集应用。

ADAS ICV307 隔离信号采集板 英文介绍

ADAS ICV307 Isolation Signal Acquisition Board Product Features:

Supports 6 independent 32-bit counting channels

Each channel is equipped with four inputs: A, B, select, and clear

Supports multiple input levels including+5V,+12V,+15V, and+24V

Built in filtering circuit, suitable for interference environment

Can be directly connected to incremental encoders

Supports X1 and X4 counting modes

Isolation input withstand voltage up to 2500V

Low input current, about 6mA

High speed counting supports up to 5MHz

Equipped with 2 time bases and 1 programmable clock

Multiple working modes can be programmed through VME bus

Supports 26 programmable interrupt sources

Compatible with VME ANSI/IEEE 1014 standard

Fully compatible with ICV 306 hardware and software

Suitable for industrial counting and signal acquisition scenarios

Summary: The ADAS ICV307 isolation signal acquisition board features 6 high-speed 32-bit counting channels, a maximum isolation withstand voltage of 2500V, and compatibility with multiple input levels. It is suitable for encoder counting and industrial signal acquisition applications.

ADAS ICV307 隔离信号采集板 产品展示
