ADAS STB306 总线信号调理板 PDF资料

1.产 品 资 料 介 绍：

ADAS STB306 总线信号调理板产品特点：

支持主流车载总线协议信号接入

具备信号滤波功能，有效抑制高频噪声

内置信号整形电路，恢复畸变波形

支持信号增益调节，补偿长线传输衰减

输入输出端电气隔离，保护后端测试设备

终端电阻可配置，匹配总线阻抗

支持总线信号无损分接，旁路监听不干扰通讯

宽压供电设计，兼容多种测试平台

接口采用标准连接器，即插即用

板载状态指示灯，实时显示信号通断

紧凑金属外壳封装，屏蔽电磁干扰

差分阻抗严格受控，保证信号完整性

支持-40℃~85℃宽温工作环境

双通道独立调理，互不串扰

适用于ADAS系统总线测试与仿真场景

总结：ADAS STB306 总线信号调理板通过滤波整形、电气隔离及阻抗匹配等核心功能，为ADAS总线信号的精确采集与测试分析提供可靠保障。

ADAS STB306 总线信号调理板 英文介绍

ADAS STB306 Bus Signal Conditioning Board Product Features:

Support mainstream vehicle bus protocol signal access

Equipped with signal filtering function, effectively suppressing high-frequency noise

Built in signal shaping circuit to restore distorted waveforms

Support signal gain adjustment and compensate for long-term transmission attenuation

Electrical isolation of input and output terminals to protect backend testing equipment

The terminal resistor can be configured to match the bus impedance

Support lossless tapping of bus signals, bypass monitoring does not interfere with communication

Wide voltage power supply design, compatible with multiple testing platforms

The interface adopts standard connectors, plug and play

Onboard status indicator light, real-time display of signal on/off

Compact metal shell packaging, shielding electromagnetic interference

Differential impedance is strictly controlled to ensure signal integrity

Supports a wide temperature range of -40 ℃~85 ℃ for working environments

Dual channel independent conditioning, no crosstalk between each other

Suitable for ADAS system bus testing and simulation scenarios

Summary: The ADAS STB306 bus signal conditioning board provides reliable guarantees for accurate acquisition, testing, and analysis of ADAS bus signals through core functions such as filtering and shaping, electrical isolation, and impedance matching.
