ADAS STB6X2 双通道总线转接板 PDF资料

1.产 品 资 料 介 绍：

ADAS STB6X2 双通道总线转接板产品特点：

双通道独立电气隔离，有效抑制通道间串扰

支持高速总线信号无损透传，保证数据完整性

宽电压输入范围，兼容12V/24V车载供电系统

信号插入损耗极低，不影响总线通讯质量

内置ESD静电保护器件，抵御车载静电冲击

终端电阻可通过跳线灵活配置，匹配不同总线阻抗

配备电源及双通道通信状态指示灯，运行状态一目了然

接口采用防反插设计，避免误操作损坏设备

PCB布局紧凑合理，适合车载有限空间安装

差分阻抗严格受控，有效减少信号反射

双通道支持同时并行数据采集与注入，互不干扰

接口定义兼容市面主流诊断线束，即插即用

选用工业级物料，支持-40℃~85℃宽温工作环境

连接器配备锁紧螺钉，抗震防松脱，适用颠簸路况

支持固件在线升级，便于协议更新与功能扩展

总结：ADAS STB6X2 双通道总线转接板以双通道隔离、宽温防护和低插损为核心优势，为ADAS智能驾驶系统的总线调试与数据交互提供稳定可靠的硬件支撑。

ADAS STB6X2 双通道总线转接板 英文介绍

ADAS STB6X2 Dual Channel Bus Adapter Board Product Features:

Dual channel independent electrical isolation effectively suppresses crosstalk between channels

Support lossless transmission of high-speed bus signals to ensure data integrity

Wide voltage input range, compatible with 12V/24V car power supply system

The signal insertion loss is extremely low and does not affect the quality of bus communication

Built in ESD electrostatic protection device to resist the impact of vehicle static electricity

Terminal resistors can be flexibly configured through jumper wires to match different bus impedances

Equipped with power supply and dual channel communication status indicator lights, the operating status is clear at a glance

The interface adopts anti reverse insertion design to avoid damage to the equipment caused by misoperation

The PCB layout is compact and reasonable, suitable for installation in limited space in vehicles

Differential impedance is strictly controlled, effectively reducing signal reflection

Dual channel support for simultaneous parallel data acquisition and injection, without interfering with each other

Interface definition compatible with mainstream diagnostic wiring harnesses in the market, plug and play

Select industrial grade materials and support a wide temperature range of -40 ℃~85 ℃ working environment

The connector is equipped with locking screws, which are earthquake resistant and anti loosening, suitable for bumpy road conditions

Support firmware online upgrade for easy protocol updates and feature extensions

Summary: The ADAS STB6X2 dual channel bus adapter board has the core advantages of dual channel isolation, wide temperature protection, and low insertion loss, providing stable and reliable hardware support for bus debugging and data exchange of ADAS intelligent driving systems.
