1.产 品 资 料 介 绍：
ADAS STB420 是一款用于工业现场总线系统的通讯板卡，侧重解决控制系统与现场设备之间的数据链路稳定性和信号适配问题。
中间10条
该板卡支持 Profibus DP 或 Modbus RTU 等主流总线协议。
通讯端口采用差分信号传输方式，具备较强的抗共模干扰能力。
板卡内置终端电阻，可根据网络位置通过跳线选择是否启用。
支持 9.6 kbps 至 12 Mbps 之间的多种通讯速率档位。
每个通讯周期可处理最多 64 字节输入和 64 字节输出数据。
电源部分采用反接保护和过压保护设计，降低接线错误导致的损坏风险。
总线故障时能自动切换到安全输出状态，防止误动作。
可通过软件配置站地址和通讯参数，无需硬件拨码开关。
外壳采用金属屏蔽层，进一步抑制电磁干扰对通讯的影响。
与 ADAS STB 系列其他板卡共用背板总线，即插即用。
结尾
总体来看，ADAS STB420 专注于总线通讯的物理层稳定性和协议兼容性，适合对通信质量要求较高的分布式控制场景。
ADAS STB420 总线通讯板卡 英文介绍
ADAS STB420 is a communication board used in industrial fieldbus systems, focusing on solving data link stability and signal adaptation issues between control systems and field devices.
10 in the middle
This board supports mainstream bus protocols such as Profibus DP or Modbus RTU.
The communication port adopts differential signal transmission method and has strong resistance to common mode interference.
The board has a built-in terminal resistor, which can be enabled or not through jumper selection based on the network location.
Supports multiple communication speed levels between 9.6 kbps and 12 Mbps.
Each communication cycle can handle up to 64 bytes of input and 64 bytes of output data.
The power supply adopts reverse connection protection and overvoltage protection design to reduce the risk of damage caused by wiring errors.
When the bus fails, it can automatically switch to a safe output state to prevent misoperation.
The station address and communication parameters can be configured through software without the need for a hardware dip switch.
The shell adopts a metal shielding layer to further suppress the impact of electromagnetic interference on communication.
Shared backplane bus with other ADAS STB series cards, plug and play.
ending
Overall, ADAS STB420 focuses on the physical layer stability and protocol compatibility of bus communication, making it suitable for distributed control scenarios that require high communication quality.
