SK-H1-ASICBD-D1030 控制器模块 PDF资料
1.产 品 资 料 介 绍：
SK-H1-ASICBD-D1030 是罗克韦尔自动化旗下的一款专用集成电路板，专为 PowerFlex 700 系列变频器设计，用于实现高性能电机控制与数字信号处理。
中间10条
该模块属于 PowerFlex 700 系列，是变频器内部的核心控制组件。
额定电流高达 1030 安培，适用于大功率电机驱动应用。
输入电压范围为 400 至 480 VAC，适应常见工业电网标准。
采用基于 DSP 的控制方式，实现精确的转矩与速度调节。
板卡配备 60mm 内部风扇，采用强制风冷方式确保散热。
提供 H1 至 H7 共七个光纤接口，用于高速通信连接。
集成电阻、电容、晶体管等元件于单一芯片，运行速度快。
工作温度范围为 0 至 60℃，需在可控环境内安装。
兼容 PowerFlex 700 H 及 S 系列机架，便于系统集成。
具备快速启动、过程 PI 控制和惯性穿越等高级功能。
结尾
综上所述，SK-H1-ASICBD-D1030 凭借其高电流能力、DSP 控制和光纤通信接口，是 PowerFlex 700 变频器中实现高性能电机控制的核心组件。
SK-H1-ASICBD-D1030 is a dedicated integrated circuit board under Rockwell Automation, designed specifically for the PowerFlex 700 series frequency converters to achieve high-performance motor control and digital signal processing.
10 in the middle
This module belongs to the PowerFlex 700 series and is the core control component inside the frequency converter.
Rated current up to 1030 amperes, suitable for high-power motor drive applications.
The input voltage range is 400 to 480 VAC, suitable for common industrial power grid standards.
Adopting a DSP based control method to achieve precise torque and speed regulation.
The board is equipped with a 60mm internal fan and uses forced air cooling to ensure heat dissipation.
Provide seven fiber optic interfaces from H1 to H7 for high-speed communication connections.
Integrating resistors, capacitors, transistors, and other components into a single chip for fast operation.
The working temperature range is 0 to 60 ℃, and it needs to be installed in a controllable environment.
Compatible with PowerFlex 700 H and S series racks for easy system integration.
It has advanced functions such as fast start, process PI control, and inertial crossing.
ending
In summary, SK-H1-ASICBD-D1030, with its high current capability, DSP control, and fiber optic communication interface, is the core component for achieving high-performance motor control in PowerFlex 700 frequency converters.
