IS200AEPAH1BJD/JE200Z7印刷电路板 PDF资料
1.产 品 资 料 介 绍：
IS200AEPAH1BJD 是通用电气为 Mark VIe 系列控制系统设计的一块印刷电路板，主要用于风力发电的变桨控制。
中间15条特点：
属于 GE 的 WEPA 系列，专为变桨控制设计。
适用于 Mark VIe 和 Mark VIeS 风力涡轮机控制系统。
兼容单工和三模冗余两种高可靠性架构。
搭载 Intel 82576 处理器，支持高速数据处理。
软件扫描周期支持三档可调。
电源额定值为 125V DC。
提供 8 个模拟量输入通道。
提供 20 个开关量输入通道。
提供 2 个开关量输出通道。
提供 9 个继电器输出。
包含 1 个增量编码器输入接口。
包含 2 路 RS-485 串行通信接口。
具备 10BaseT 以太网接口。
板载浪涌保护器件。
安装于 VME 机架内。
结尾：
总之，IS200AEPAH1BJD 是 Mark VIe 系统中的专用控制板，适用于风力发电等需要高可靠性的工业控制场景。
IS200AEPAH1BJD/JE200Z7印刷电路板 英文介绍
IS200AEPAH1BJD is a printed circuit board designed by General Electric for the Mark VIe series control system, mainly used for pitch control in wind power generation.
The 15 characteristics in the middle:
The WEPA series belonging to GE is designed specifically for pitch control.
Suitable for Mark VIe and Mark VIeS wind turbine control systems.
It is compatible with two high reliability architectures: simplex and the third mock examination redundancy.
Equipped with Intel 82576 processor, supporting high-speed data processing.
The software scanning cycle supports three adjustable levels.
The rated value of the power supply is 125V DC.
Provide 8 analog input channels.
Provide 20 switch input channels.
Provide 2 switch output channels.
Provide 9 relay outputs.
Contains 1 incremental encoder input interface.
Contains 2 RS-485 serial communication interfaces.
Equipped with a 10BaseT Ethernet interface.
Onboard surge protection device.
Installed inside the VME rack.
Ending
In summary, IS200AEPAH1BJD is a dedicated control board in the Mark VIe system, suitable for industrial control scenarios such as wind power generation that require high reliability.
IS200AEPAH1BJD/JE200Z7印刷电路板 产品展示
