560CMU05 1KGT012700R0002通信单元模块 PDF资料
1.产 品 资 料 介 绍：
560CMU05 1KGT012700R0002是ABB公司RTU560系列的核心通信单元模块，负责系统内的数据处理与远程通信。
中间15条特点：
属于ABB RTU560远程终端单元系列。
搭载32位微处理器，数据处理能力强。
供电电压为24V DC，功耗低。
配备4个串行通信接口，可配置为RS-232或RS-485。
配备2个以太网接口，支持10/100M速率。
串口支持Modbus、IEC60870、DNP3、Profibus等协议。
以太网口支持Modbus TCP、IEC60870-104等协议。
通过内部总线管理机架内所有I/O模块。
内置非易失性存储，断电后参数不丢失。
支持热插拔，可在运行状态下更换模块。
工作温度范围-20℃至+60℃。
防护等级IP20，抗振动、抗电磁干扰能力强。
配备LED指示灯，显示电源、通信、运行及故障状态。
尺寸约203×140×58mm，占用RTU560机架2个插槽。
适用于电力变电站、油气管道、水利泵站等远程监控领域。
结尾：
总之，560CMU05是一款高性能、多协议、宽温工作的核心通信模块，适用于工业远程监控和SCADA系统。
560CMU05 1KGT012700R0002通信单元模块 英文介绍
560CMU05 1KGT012700R0002 is the core communication unit module of ABB's RTU560 series, responsible for data processing and remote communication within the system.
The 15 characteristics in the middle:
Belongs to the ABB RTU560 remote terminal unit series.
Equipped with a 32-bit microprocessor, it has strong data processing capabilities.
The power supply voltage is 24V DC, with low power consumption.
Equipped with 4 serial communication interfaces, configurable as RS-232 or RS-485.
Equipped with 2 Ethernet interfaces, supporting 10/100M speed.
The serial port supports protocols such as Modbus, IEC60870, DNP3, Profibus, etc.
The Ethernet port supports protocols such as Modbus TCP and IEC60870-104.
Manage all I/O modules within the rack through an internal bus.
Built in non-volatile storage, parameters are not lost after power failure.
Supports hot swapping and allows for module replacement while in operation.
The working temperature range is -20 ℃ to+60 ℃.
Protection level IP20, strong resistance to vibration and electromagnetic interference.
Equipped with LED indicator lights to display power, communication, operation, and fault status.
The size is approximately 203 × 140 × 58mm, occupying 2 slots in the RTU560 rack.
Suitable for remote monitoring fields such as power substations, oil and gas pipelines, and water pump stations.
Ending
In summary, 560CMU05 is a high-performance, multi protocol, and wide temperature working core communication module suitable for industrial remote monitoring and SCADA systems.
560CMU05 1KGT012700R0002通信单元模块 产品展示
