Woodward 9906-619数字控制模块 PDF资料
1.产 品 资 料 介 绍：
Woodward 9906-619是一款用于涡轮机和发电机组的数字控制模块。
中间15条特点：
属于Woodward 723PLUS系列数字控制器。
输入电压范围为18至40V DC，标称24V或32V。
支持转速控制、负荷控制、同步控制等多种功能。
可实现多台机组之间的比例负载分配。
配备2个转速输入接口，兼容磁电传感器和接近开关。
提供4个模拟量输入通道，用于采集各类传感器信号。
提供3个模拟量输出通道，用于控制执行机构。
提供8个数字量输入和3个数字量输出通道。
操作面板配有背光液晶显示屏，方便现场查看。
支持Modbus通信协议，可与上位机系统交换数据。
具备超速保护功能，确保设备运行安全。
具备临界转速规避功能，避免机械共振损伤。
工作温度范围宽，从-40℃至+70℃适应恶劣环境。
断电后所有设定值自动保存在内部存储器中。
广泛应用于发电厂、石油化工、船舶推进等工业领域。
结尾：
总之，Woodward 9906-619具备丰富的控制功能、齐全的接口通道和可靠的环境适应性，是工业涡轮机控制系统的核心部件。
Woodward 9906-619 is a digital control module used for turbines and generator sets.
The 15 characteristics in the middle:
Belongs to the Woodward 723PLUS series digital controller.
The input voltage range is 18 to 40V DC, with nominal 24V or 32V.
Supports multiple functions such as speed control, load control, and synchronous control.
It can achieve proportional load distribution among multiple units.
Equipped with 2 speed input interfaces, compatible with magneto electric sensors and proximity switches.
Provide 4 analog input channels for collecting various sensor signals.
Provide 3 analog output channels for controlling the actuator.
Provide 8 digital input channels and 3 digital output channels.
The operation panel is equipped with a backlit LCD display screen for easy on-site viewing.
Supports Modbus communication protocol and can exchange data with the upper computer system.
Equipped with overspeed protection function to ensure safe operation of the equipment.
Equipped with critical speed avoidance function to prevent mechanical resonance damage.
Wide working temperature range, from -40 ℃ to+70 ℃, suitable for harsh environments.
After power failure, all set values are automatically saved in the internal memory.
It is widely used in power plants, petrochemical industry, ship propulsion and other industrial fields.
Ending
In summary, Woodward 9906-619 has rich control functions, complete interface channels, and reliable environmental adaptability, making it the core component of industrial turbine control systems.
