XV-303-15-C00-A00-1B操作面板 PDF资料
1.产 品 资 料 介 绍：
Eaton XV-303-15-C00-A00-1B 操作面板产品特点
开头：
Eaton XV-303-15-C00-A00-1B 是伊顿 XV300 系列的一款高性能人机界面操作面板，集 15.6 英寸宽屏触摸显示与工业级控制功能于一体，适用于工厂自动化、过程监控及设备控制等工业场景。
中间（15条特点）：
属于 Eaton XV300 系列高级人机界面产品。
显示屏尺寸 15.6 英寸，16:9 宽屏比例。
屏幕类型为 TFT 彩色液晶，分辨率 1366×768 像素。
采用投射电容式多点触控技术，支持多指操作。
屏幕亮度 300 cd/m²，对比度 500:1，可视角度宽。
前面板防护等级 IP65，防尘防水，适应恶劣环境。
铝合金压铸外壳，正面覆盖防眩光钢化玻璃。
搭载 ARM Cortex-A9 800MHz 处理器。
内存配置：512MB 内存、1GB 闪存、128KB 非易失性存储。
操作系统采用 Windows Embedded Compact 7 Pro。
内置 2 路 10/100Mbps 以太网接口。
通信接口丰富：RS232、RS485、CAN、USB 主机及 USB 设备。
支持 SD 卡扩展外部存储。
工作温度范围 0℃ 至 50℃，相对湿度 10% 至 95%。
无风扇被动散热设计，整机重量约 3.9kg。
结尾：
综上所述，Eaton XV-303-15-C00-A00-1B 操作面板具有大尺寸高清显示、多点触控、接口丰富及高防护等级等特点，是满足工业自动化人机交互与控制需求的可靠设备。
Eaton XV-303-15-C00-A00-1B Operation Panel Product Features
beginning
Eaton XV-303-15-C00-A00-1B is a high-performance human-machine interface control panel of Eaton XV300 series, which integrates 15.6-inch widescreen touch display and industrial grade control functions, suitable for industrial scenarios such as factory automation, process monitoring, and equipment control.
Middle (15 characteristics):
Belonging to the Eaton XV300 series of advanced human-machine interface products.
Display screen size 15.6 inches, 16:9 widescreen ratio.
The screen type is TFT color LCD with a resolution of 1366 × 768 pixels.
Adopting projected capacitive multi touch technology, supporting multi finger operation.
The screen brightness is 300 cd/m ², the contrast ratio is 500:1, and the viewing angle is wide.
The front panel protection level is IP65, dustproof and waterproof, suitable for harsh environments.
Aluminum alloy die-casting shell, front covered with anti glare tempered glass.
Equipped with ARM Cortex-A9 800MHz processor.
Memory configuration: 512MB memory, 1GB flash memory, 128KB non-volatile storage.
The operating system adopts Windows Embedded Compact 7 Pro.
Built in 2 channels of 10/100Mbps Ethernet interfaces.
Rich communication interfaces: RS232, RS485, CAN, USB host and USB devices.
Support SD card expansion for external storage.
The working temperature range is 0 ℃ to 50 ℃, and the relative humidity is 10% to 95%.
Fanless passive cooling design, with a total weight of approximately 3.9kg.
Ending
In summary, the Eaton XV-303-15-C00-A00-1B control panel has the characteristics of large-sized high-definition display, multi touch, rich interfaces, and high protection level, making it a reliable device that meets the needs of industrial automation human-machine interaction and control.
