MSM030C-0300-NN-M0-CG0伺服电机 PDF资料
1.产 品 资 料 介 绍：
Bosch Rexroth MSM030C-0300-NN-M0-CG0 伺服电机产品特点
开头：
Bosch Rexroth MSM030C-0300-NN-M0-CG0 是德国博世力士乐集团推出的一款高性能三相永磁同步伺服电机，属于 MSM 系列，额定功率 400W，专为工业自动化领域的高精度运动控制而设计。
中间（15条特点）：
额定功率 400W，属于 MSM 系列小功率伺服电机。
额定转速 3000 rpm，最高转速可达 5000 rpm。
机座规格为 30，机座长度为 C。
采用自然对流冷却方式，无需外部风扇。
配备多圈绝对值编码器，分辨率 17 位。
编码器最高转速支持 6000 rpm。
轴端为光轴设计，无键槽。
未配备抱闸。
电气连接方式为电缆拖尾式。
机壳防护等级 IP65，输出轴防护等级 IP40。
静止状态连续扭矩 1.2 Nm，连续电流 2.3 A。
转子惯量 0.17 × 10⁻⁴ kgm²，适合高动态响应。
绕组电感 17 ± 10% mH。
绝缘等级 Class B。
电机重量约 1.5 kg，体积紧凑。
结尾：
综上所述，Bosch Rexroth MSM030C-0300-NN-M0-CG0 伺服电机具有功率适中、转速范围宽、编码器精度高、防护等级可靠等特点，是满足工业自动化设备精准运动控制需求的理想驱动组件。
MSM030C-0300-NN-M0-CG0伺服电机 英文介绍
Bosch Rexroth MSM030C-0300-NN-M0-CG0 servo motor product features
beginning
Bosch Rexroth MSM030C-0300-NN-M0-CG0 is a high-performance three-phase permanent magnet synchronous servo motor launched by Bosch Rexroth Group in Germany, belonging to the MSM series. This model has a rated power of 400W and is designed specifically for high-precision motion control in the field of industrial automation.
Middle (15 characteristics):
The rated power is 400W, belonging to the MSM series low-power servo motor.
The rated speed is 3000 rpm, and the maximum speed can reach 5000 rpm.
The machine base has a specification of 30 and a length of C.
Adopting natural convection cooling method, no external fan is required.
Equipped with a multi turn absolute value encoder with a resolution of 17 bits.
The encoder supports a maximum speed of 6000 rpm.
The shaft end is designed as the optical axis without keyway.
Not equipped with brake.
The electrical connection method is cable trailing.
The enclosure protection level is IP65, and the output shaft protection level is IP40.
Static state continuous torque 1.2 Nm, continuous current 2.3 A.
The rotor inertia is 0.17 × 10 ⁻⁴ kgm ², suitable for high dynamic response.
Winding inductance 17 ± 10% mH.
Insulation Class B.
The motor weighs about 1.5 kg and has a compact size.
Ending
In summary, the Bosch Rexroth MSM030C-0300-NN-M0-CG0 servo motor has the characteristics of moderate power, wide speed range, high encoder accuracy, and reliable protection level, making it an ideal driving component to meet the precise motion control needs of industrial automation equipment.
MSM030C-0300-NN-M0-CG0伺服电机 产品展示
