93-3004-01 1MRK002122-ABR07继电器接口模块 PDF资料
1.产 品 资 料 介 绍：
ABB 93-3004-01 1MRK002122-ABR07 继电器接口模块产品特点
开头：
ABB 93-3004-01 1MRK002122-ABR07 是专为 Relion® 615 系列保护继电器设计的内部接口模块，适用于 RED615、REF615 等馈线保护装置，承担信号隔离、协议转换与接口适配功能。
中间（15条特点）：
适配 ABB RED615、REF615、REM615、RET615 等 615 系列保护继电器。
后缀 ABr07 表示特定功能授权与配置包，不可随意替换。
支持 IEC 61850 标准，含 GOOSE 快速跳闸与 MMS 服务。
GOOSE 跳闸命令传输时间小于 4 毫秒。
兼容 Modbus RTU/TCP、DNP3、IEC 60870-5-103 等协议。
配备 RS485 接口及可选光纤接口，光纤传输距离可达 20 公里。
支持 8 路隔离数字输入和 6 路继电器输出。
支持 4 路隔离模拟量输入，精度 ±0.1%。
电气隔离电压 2.5kV，有效阻断现场干扰信号。
工作温度范围 -40℃ 至 +85℃，适应各类恶劣环境。
防护等级 IP20，适合控制柜内安装。
采用 35mm DIN 导轨安装，结构紧凑。
面板 LED 指示灯，可直观判断电源、通信及故障状态。
支持热插拔维护，减少系统停机时间。
平均无故障时间不低于 10 万小时，可靠性高。
结尾：
综上所述，ABB 93-3004-01 1MRK002122-ABR07 接口模块具有协议兼容性强、电气隔离可靠、工作温度范围宽等特点，是保障 Relion 615 系列保护装置稳定运行的核心组件。
93-3004-01 1MRK002122-ABR07继电器接口模块 英文介绍
ABB 93-3004-01 1MRK002122-ABR07 Relay Interface Module Product Features
beginning
ABB 93-3004-01 1MRK002122-ABR07 is specifically designed for Relion ® The internal interface module designed for the 615 series protective relay is suitable for feeder protection devices such as RED615 and REF615, and is responsible for signal isolation, protocol conversion, and interface adaptation functions.
Middle (15 characteristics):
Suitable for ABB RED615, REF615, REM615, RET615 and other 615 series protection relays.
The suffix ABr07 represents a specific function authorization and configuration package, which cannot be replaced arbitrarily.
Supports IEC 61850 standard, including GOOSE fast tripping and MMS services.
GOOSE trip command transmission time is less than 4 milliseconds.
Compatible with protocols such as Modbus RTU/TCP, DNP3, IEC 60870-5-103, etc.
Equipped with RS485 interface and optional fiber optic interface, the fiber optic transmission distance can reach 20 kilometers.
Supports 8 isolated digital inputs and 6 relay outputs.
Supports 4-channel isolated analog input with an accuracy of ± 0.1%.
The electrical isolation voltage is 2.5kV, effectively blocking on-site interference signals.
The working temperature range is -40 ℃ to+85 ℃, suitable for various harsh environments.
Protection level IP20, suitable for installation inside control cabinets.
Adopting 35mm DIN rail installation, the structure is compact.
The panel LED indicator light can intuitively determine the power, communication, and fault status.
Support hot swappable maintenance to reduce system downtime.
The average time between failures is not less than 100000 hours, with high reliability.
Ending
In summary, the ABB 93-3004-01 1MRK002122-ABR07 interface module has strong protocol compatibility, reliable electrical isolation, and a wide operating temperature range. It is the core component that ensures the stable operation of the Relion 615 series protection device.
