93-3004-04 1MRK002122-ABR12接口板 PDF资料
1.产 品 资 料 介 绍：
ABB 93-3004-04 1MRK002122-ABR12 接口板产品特点
开头：
ABB 93-3004-04 1MRK002122-ABR12 是 Relion® REF615 系列的一款馈线保护与测控继电器接口板，专为中压配电网络设计，集成保护、控制、测量与 IEC 61850 通信功能于一体。
中间（15条特点）：
适配 ABB Relion REF615 系列馈线保护装置。
额定 CT 输入为 1A，适用于高精度计量与长距离 CT 布线场景。
集成相过流、接地过流、断路器失灵、热过载等保护功能。
支持自动重合闸逻辑，时序可灵活整定。
支持 IEC 61850 Edition 2 标准，包括 MMS 及 GOOSE 快速报文服务。
支持 GOOSE 点对点通信，实现装置间毫秒级联锁与跳闸信号传输。
兼容 Modbus RTU/TCP、DNP3、IEC 60870-5-103 等多种通信协议。
配备双以太网端口，支持冗余网络配置。
供电方式为 24-250V DC 或 100-240V AC 宽范围自适应。
配备彩色图形显示屏，支持本地操作与查看实时数据。
内置故障录波与事件记录功能，便于故障分析诊断。
支持 IRIG-B 或 SNTP 高精度时间同步。
工作温度范围 -25℃ 至 +55℃，适应变电站环境。
支持开孔安装或表面安装，标准 4U 高度。
符合 NERC CIP、IEC 62351 等网络安全标准，支持角色权限管理。
结尾：
综上所述，ABB 93-3004-04 1MRK002122-ABR12 接口板具有保护功能全面、协议兼容性强、配置灵活等特点，是保障中压配电网络安全稳定运行的核心设备。
93-3004-04 1MRK002122-ABR12接口板 英文介绍
ABB 93-3004-04 1MRK002122-ABR12 Interface Board Product Features
beginning
ABB 93-3004-04 1MRK002122-ABR12 is Relion ® The REF615 series is a feeder protection and measurement relay interface board designed specifically for medium voltage distribution networks, integrating protection, control, measurement, and IEC 61850 communication functions.
Middle (15 characteristics):
Suitable for ABB Relion REF615 series feeder protection device.
The rated CT input is 1A, suitable for high-precision measurement and long-distance CT wiring scenarios.
Integrate protection functions such as phase overcurrent, grounding overcurrent, circuit breaker failure, and thermal overload.
Support automatic reclosing logic and flexible timing adjustment.
Supports IEC 61850 Edition 2 standard, including MMS and GOOSE Fast Message Service.
Support GOOSE point-to-point communication to achieve millisecond level interlocking and trip signal transmission between devices.
Compatible with various communication protocols such as Modbus RTU/TCP, DNP3, IEC 60870-5-103, etc.
Equipped with dual Ethernet ports, supporting redundant network configurations.
The power supply mode is 24-250V DC or 100-240V AC wide range adaptive.
Equipped with a color graphic display screen, supporting local operation and real-time data viewing.
Built in fault recording and event recording functions facilitate fault analysis and diagnosis.
Supports IRIG-B or SNTP high-precision time synchronization.
The working temperature range is -25 ℃ to+55 ℃, suitable for the substation environment.
Supports open hole installation or surface installation, with a standard height of 4U.
Compliant with NERC CIP, IEC 62351 and other network security standards, supporting role permission management.
Ending
In summary, the ABB 93-3004-04 1MRK002122-ABR12 interface board has comprehensive protection functions, strong protocol compatibility, and flexible configuration, making it a core equipment for ensuring the safe and stable operation of medium voltage distribution networks.
93-3004-04 1MRK002122-ABR12接口板 产品展示
