1MRK002122-ABR00印刷电路板 PDF资料
1.产 品 资 料 介 绍：
ABB 1MRK002122-ABR00 印刷电路板产品特点
开头：
ABB 1MRK002122-ABR00 是一款专为 Relion® REF54_ 系列及 REF615 保护测控装置设计的通信处理器印刷电路板，负责保护装置与外部监控系统之间的协议转换与数据交换任务。
中间（15条特点）：
适配 ABB REF541、REF543、REF545 及 REF615 等保护装置。
由主机背板直接供电，无需外接电源。
支持 SPA 总线及 IEC 60870-5-103 标准电力规约。
配备 RS-485 串行接口及专用背板连接器。
工业级加固设计，防护等级高。
工作温度范围 -20℃ 至 +70℃。
存储温度范围 -40℃ 至 +85℃。
支持高湿度环境运行，无冷凝。
抗电磁干扰能力强，符合相关标准。
采用背板插拔安装方式，替换快速便捷。
具备协议转换、数据封装及通信链路管理功能。
保障保护装置遥测、遥信、遥控、遥调功能实现。
模块化设计，支持独立更换与升级。
符合多项国际认证标准。
作为原厂关键备件，确保系统稳定运行。
结尾：
综上所述，ABB 1MRK002122-ABR00 印刷电路板具有适配性强、安装便捷、抗干扰能力出色等特点，是保障 Relion 系列保护装置通信功能稳定可靠的核心组件。
ABB 1MRK002122-ABR00 Printed Circuit Board Product Features
beginning
ABB 1MRK002122-ABR00 is a product specifically designed for Relion ® The communication processor printed circuit board designed for the REF54_ series and REF615 protection and measurement devices is responsible for protocol conversion and data exchange tasks between the protection devices and external monitoring systems.
Middle (15 characteristics):
Suitable for ABB REF541, REF543, REF545, and REF615 protective devices.
Powered directly by the motherboard without the need for an external power source.
Supports SPA bus and IEC 60870-5-103 standard power protocol.
Equipped with RS-485 serial interface and dedicated backplane connector.
Industrial grade reinforcement design with high protection level.
The working temperature range is -20 ℃ to+70 ℃.
The storage temperature range is -40 ℃ to+85 ℃.
Supports operation in high humidity environments without condensation.
Strong anti-interference ability, in compliance with relevant standards.
Adopting the backplane plug-in installation method, replacement is fast and convenient.
Capable of protocol conversion, data encapsulation, and communication link management.
Ensure the implementation of telemetry, remote signaling, remote control, and remote adjustment functions for protective devices.
Modular design, supporting independent replacement and upgrade.
Compliant with multiple international certification standards.
As a key spare part of the original factory, ensure the stable operation of the system.
Ending
In summary, ABB 1MRK002122-ABR00 printed circuit board has the characteristics of strong adaptability, easy installation, and excellent anti-interference ability. It is the core component that ensures the stable and reliable communication function of Relion series protection devices.
