1MRK002122-ABR05保护继电器接口模块 PDF资料
1.产 品 资 料 介 绍：
ABB 1MRK002122-ABR05 保护继电器接口模块产品特点
开头：
ABB 1MRK002122-ABR05 是一款专为 REF615 等 Relion 系列保护继电器设计的光纤通信接口模块，用于保护装置与上位系统之间的数据交换。
中间（15条特点）：
专用于 ABB REF615 及 REF54_ 系列保护继电器。
支持光纤通信，传输距离可达 2 公里。
支持 RS-485 接口，速率 9.6kbps 至 100Mbps。
兼容 IEC 61850、Modbus、DNP3.0、IEC 60870-5-103 等协议。
由主机背板供电，无需外接电源。
低功耗设计，功耗不超过 5W。
抗电磁干扰能力强，适用于变电站环境。
工作温度 -20℃ 至 +70℃。
防护等级 IP20，适合机箱内安装。
直接插入主机背板插槽，免工具安装。
紧凑设计，重量轻，便于运输。
内置通信诊断与故障报警功能。
传输延迟低，丢包率小于 0.1%。
无需额外网关，可直接对接主流工控系统。
配合 REF615 的过流、接地故障、重合闸等保护逻辑使用。
结尾：
综上所述，ABB 1MRK002122-ABR05 接口模块兼容性强、安装便捷、通信可靠，是 Relion 系列保护装置的核心通信组件。
1MRK002122-ABR05保护继电器接口模块 英文介绍
Product Features of ABB 1MRK002122-ABR05 Protection Relay Interface Module
beginning
ABB 1MRK002122-ABR05 is a fiber optic communication interface module designed specifically for Relion series protection relays such as REF615, used for data exchange between protection devices and upper level systems.
Middle (15 characteristics):
Specially designed for ABB REF615 and REF54_ series protective relays.
Supports fiber optic communication, with a transmission distance of up to 2 kilometers.
Supports RS-485 interface, with speeds ranging from 9.6kbps to 100Mbps.
Compatible with protocols such as IEC 61850, Modbus, DNP3.0, IEC 60870-5-103, etc.
Powered by the motherboard, no external power supply is required.
Low power design, with power consumption not exceeding 5W.
Strong anti-interference ability, suitable for substation environment.
The working temperature ranges from -20 ℃ to+70 ℃.
Protection level IP20, suitable for installation inside the chassis.
Directly insert into the motherboard slot for tool free installation.
Compact design, lightweight, and easy to transport.
Built in communication diagnosis and fault alarm function.
Low transmission latency, with a packet loss rate of less than 0.1%.
No additional gateway is required, it can directly interface with mainstream industrial control systems.
Used in conjunction with the overcurrent, ground fault, reclosing and other protection logic of REF615.
Ending
In summary, the ABB 1MRK002122-ABR05 interface module has strong compatibility, easy installation, and reliable communication, making it the core communication component of the Relion series protection devices.
