1MRK002122-ABR01接口模块 PDF资料
1.产 品 资 料 介 绍：
ABB 1MRK002122-ABR01 接口模块产品特点
开头：
ABB 1MRK002122-ABR01 是一款专为 Relion® 670/650 系列保护装置设计的光纤通信与二进制 I/O 接口模块，用于实现保护装置与变电站自动化系统之间的数据交换和信号处理。
中间（15条特点）：
专用于 ABB Relion 670 系列及 REF615 等保护装置。
配备 2 个 ST 型多模光纤接口，支持板间点对点通信。
光纤传输距离可达 500 米，抗电磁干扰能力强。
通信速率 100Mbps，满足保护信号的实时性要求。
支持 IEC 61850-8-1、IEC 60870-5-103 等主流通信协议。
具备二进制输入输出通道，可连接断路器、信号灯等现场设备。
额定工作电压 24V DC，额定电流 1.0A。
支持 PRP/HSR 网络冗余协议，确保通信链路单点故障时不中断。
通过背板金手指与保护装置内部总线连接，支持热插拔维护。
电气隔离电压 2.5kV AC，有效阻断现场干扰。
工作温度范围 -40℃ 至 +70℃，适应各类恶劣环境。
采用 35mm 标准 DIN 导轨安装，结构紧凑节省空间。
面板配备 LED 状态指示灯，可直观判断链路通断和工作状态。
支持 GOOSE 快速报文传输，实现装置间毫秒级跳闸信号交互。
本体轻量化设计，重量约 0.17-0.2kg，便于安装运输。
结尾：
综上所述，ABB 1MRK002122-ABR01 接口模块集光纤通信、二进制 I/O 和协议转换功能于一体，具有高速可靠、抗干扰强、安装便捷等特点，是保障 Relion 系列保护装置稳定运行的关键组件。
Product Features of ABB 1MRK002122-ABR01 Interface Module
beginning
ABB 1MRK002122-ABR01 is a product specifically designed for Relion ® The fiber optic communication and binary I/O interface module designed for the 670/650 series protection device is used to achieve data exchange and signal processing between the protection device and the substation automation system.
Middle (15 characteristics):
Specially designed for ABB Relion 670 series and REF615 protection devices.
Equipped with 2 ST type multimode fiber interfaces, supporting point-to-point communication between boards.
Fiber optic transmission can reach a distance of up to 500 meters and has strong resistance to electromagnetic interference.
The communication speed is 100Mbps, which meets the real-time requirements for protecting signals.
Supports mainstream communication protocols such as IEC 61850-8-1 and IEC 60870-5-103.
Equipped with binary input and output channels, it can connect to on-site devices such as circuit breakers and signal lights.
Rated working voltage 24V DC, rated current 1.0A.
Support PRP/HSR network redundancy protocol to ensure uninterrupted communication in the event of a single point of failure.
Connected to the internal bus of the protective device through the backplane gold finger, it supports hot swappable maintenance.
The electrical isolation voltage is 2.5kV AC, effectively blocking on-site interference.
The working temperature range is -40 ℃ to+70 ℃, suitable for various harsh environments.
Adopting 35mm standard DIN rail installation, the structure is compact and space saving.
The panel is equipped with LED status indicator lights, which can intuitively determine the connection and working status of the link.
Support GOOSE fast message transmission and achieve millisecond level trip signal interaction between devices.
The lightweight design of the body weighs approximately 0.17-0.2kg, making it easy to install and transport.
Ending
In summary, the ABB 1MRK002122-ABR01 interface module integrates fiber optic communication, binary I/O, and protocol conversion functions, and has the characteristics of high-speed reliability, strong anti-interference, and easy installation. It is a key component to ensure the stable operation of the Relion series protection devices.
