NI PCI-6561分析仪模块 PDF资料
1.产 品 资 料 介 绍：
NI PCI-6561分析仪模块作为National Instruments的高速数字波形发生器/分析仪，具备以下15条主要产品特点：
中间15条：
200 Mb/s最大数据速率（双倍数据速率DDR模式）。
100 MHz最大时钟频率，满足高速数字测试需求。
16路LVDS（低压差分信号）数字通道。
单倍数据速率模式下每通道可独立控制方向。
板载每通道2Mb/16Mb/128Mb可选深度内存。
支持模式序列生成与多级触发功能。
LVDS差分信号设计，功耗低、抗干扰能力强。
通道间偏移小，典型值±215ps（发生）/±330ps（采集）。
数据延迟分辨率高达60ps，满足精密时序控制。
支持内外部时钟源，灵活适配不同测试场景。
基于NI同步与存储核心架构，可与其他仪器紧密同步。
搭配NI数字波形编辑器软件，可交互式创建和编辑波形。
支持从VHDL仿真和电子表格导入波形。
32-bit PCI总线接口，半长卡设计，适用于标准台式机。
软件支持NI-HSDIO驱动及LabVIEW、C/C++、MATLAB等开发环境。
结尾：
总结而言，NI PCI-6561分析仪模块具有高速率、低功耗、多通道、深存储和灵活同步五大核心优势，是半导体器件测试与高速数字接口验证的理想选择。
NI PCI-6561分析仪模块 英文介绍
The NI PCI-6561 analyzer module, as a high-speed digital waveform generator/analyzer from National Instruments, has the following 15 main product features:
Middle 15:
Maximum data rate of 200 Mb/s (double data rate DDR mode).
The maximum clock frequency of 100 MHz meets the requirements of high-speed digital testing.
16 LVDS (Low Voltage Differential Signaling) digital channels.
In single data rate mode, each channel can independently control the direction.
Onboard 2Mb/16Mb/128Mb optional depth memory per channel.
Support pattern sequence generation and multi-level triggering function.
LVDS differential signal design, low power consumption, strong anti-interference ability.
The inter channel offset is small, with a typical value of ± 215ps (occurrence)/± 330ps (acquisition).
The data delay resolution is as high as 60ps, meeting the requirements of precise timing control.
Support internal and external clock sources, flexibly adapting to different testing scenarios.
Based on NI synchronization and storage core architecture, it can be closely synchronized with other instruments.
Paired with NI digital waveform editor software, it can interactively create and edit waveforms.
Support importing waveforms from VHDL simulations and spreadsheets.
32-bit PCI bus interface, half length card design, suitable for standard desktop computers.
The software supports NI-HSDIO drivers and development environments such as LabVIEW, C/C++, MATLAB, etc.
Ending
In summary, the NI PCI-6561 analyzer module has five core advantages: high speed, low power consumption, multi-channel, deep storage, and flexible synchronization, making it an ideal choice for semiconductor device testing and high-speed digital interface verification.
NI PCI-6561分析仪模块 产品展示
