Matrox Genesis 63039620241采集卡  PDF资料

1.产 品 资 料 介 绍：

Matrox Genesis 63039620241 采集卡是加拿大Matrox公司推出的高性能图像采集与处理板卡，其核心特点总结如下：

1. 部件编号63039620241，对应Genesis系列720-04 Grab GEN/F/64/8/LVDS型号。

2. 长PCI板卡规格，集图像采集、实时处理与显示功能于一体。

3. 搭载TI TMS320C80多核DSP处理器，运算能力高达100 BOPs。

4. 配备Matrox NOA邻域运算加速器，加速图像处理算法。

5. 模拟采集速率高达140 MHz，32位数字采集达30 MHz。

6. 支持RS-422（25 MHz）和LVDS（40 MHz）数字接口。

7. 可同时采集多达4路同步视频流。

8. 板载6 MB WRAM显示缓存和2 MB WRAM叠加缓存。

9. VGA显示分辨率高达1600 x 1200 @ 85 Hz。

10. 支持真彩色显示及无损伪彩色图形叠加。

11. 采用VMChannel™次级总线，支持多板卡级联传输。

12. 适用于工业机器视觉、医疗影像及科研成像领域。

13. 可接入多种视频源：RGB/黑白、模拟/数字、面阵/线阵相机。

14. 支持Windows NT 4.0、2000、XP及QNX操作系统。

15. 配套Matrox Imaging Library（MIL）软件开发包。

结尾： 综上所述，Matrox Genesis 63039620241 采集卡具有采集速率高、处理性能强及接口兼容性广的特点，是工业成像与医疗影像系统中的核心视频采集处理部件。

Matrox Genesis 63039620241采集卡  英文介绍

The Matrox Genesis 63039620241 acquisition card is a high-performance image acquisition and processing board launched by the Canadian company Matrox. Its core features are summarized as follows:

Part number 63039620241, corresponding to Genesis series 720-04 Grab GEN/F/64/8/LVDS model.

Long PCI board specifications, integrating image acquisition, real-time processing, and display functions.

Equipped with TI TMS320C80 multi-core DSP processor, with a computing power of up to 100 BOPs.

Equipped with Matrox NOA neighborhood operation accelerator to accelerate image processing algorithms.

The analog acquisition rate is up to 140 MHz, and the 32-bit digital acquisition rate is up to 30 MHz.

Supports RS-422 (25 MHz) and LVDS (40 MHz) digital interfaces.

Can simultaneously capture up to 4 synchronized video streams.

Onboard 6 MB WRAM display cache and 2 MB WRAM overlay cache.

VGA display resolution up to 1600 x 1200 @ 85 Hz.

Supports true color display and lossless pseudocolor graphic overlay.

Adopting VMChannel ™ Secondary bus, supporting cascading transmission of multiple boards.

Suitable for industrial machine vision, medical imaging, and scientific imaging fields.

Multiple video sources can be connected: RGB/black and white, analog/digital, and area/line array cameras.

Supports Windows NT 4.0, 2000, XP, and QNX operating systems.

Matched with Matrox Imaging Library (MIL) software development kit.

Conclusion: In summary, the Matrox Genesis 63039620241 acquisition card has the characteristics of high acquisition rate, strong processing performance, and wide interface compatibility. It is the core video acquisition and processing component in industrial imaging and medical imaging systems.

Matrox Genesis 63039620241采集卡  产品展示
