ACH550-UH-246A-4驱动器 PDF资料

1.产 品 资 料 介 绍：

ABB ACH550-UH-246A-4 是ABB ACH550系列中一款大功率 HVAC 专用变频器，额定电流245A、功率200HP（约150kW），专为风机、水泵、压缩机等暖通空调负载设计。

产品特点（15条）

1. 额定输出245A，连续电流输出能力强

2. 200HP大功率，适配约150kW交流电机

3. 三相480V输入，电压范围308-480V AC

4. R6大框架尺寸，适合壁挂安装

5. IP21防护等级，符合NEMA 1室内安装标准

6. 标配操作面板，支持手动/自动/关机三模式切换

7. 内置BACnet和Modbus RTU双协议

8. 集成RS485接口，便于现场总线组网

9. 支持拆卸EMC滤波螺丝，适配IT不接地系统

10. 采用闪通制动技术，无需外接制动电阻

11. 内置送风机、冷却塔等多种HVAC专用宏

12. 支持电机参数自学习，自动优化控制

13. 内置过流、过压、过热、短路多重保护

14. 配备强制风冷散热，适应持续负荷运行

15. 额定运行温度40°C，适应典型机房环境

结尾

ACH550-UH-246A-4 以245A大功率输出、HVAC专用功能及楼宇总线兼容性为核心优势，是大型风机水泵类负载节能改造的可靠选择。

ACH550-UH-246A-4驱动器  英文介绍

ABB ACH550-UH-246A-4 is a high-power HVAC dedicated frequency converter in the ABB ACH550 series, with a rated current of 245A and a power of 200HP (approximately 150kW), designed specifically for HVAC loads such as fans, water pumps, compressors, etc.

Product features (15 items)

Rated output of 245A, strong continuous current output capability

200HP high power, compatible with approximately 150kW AC motor

Three phase 480V input, voltage range 308-480V AC

R6 large frame size, suitable for wall mounted installation

IP21 protection level, compliant with NEMA 1 indoor installation standard

Standard operation panel, supporting manual/automatic/shutdown three mode switching

Built in BACnet and Modbus RTU dual protocols

Integrated RS485 interface for easy fieldbus networking

Support disassembling EMC filter screws and adapting to IT ungrounded systems

Adopting flash through braking technology, no external braking resistor is required

Built in HVAC specific macros such as air supply fans and cooling towers

Support self-learning of motor parameters and automatic optimization control

Built in multiple protections for overcurrent, overvoltage, overheating, and short circuit

Equipped with forced air cooling for continuous load operation

Rated operating temperature of 40 ° C, suitable for typical computer room environment

ending

ACH550-UH-246A-4 has the core advantages of 245A high-power output, HVAC dedicated functions, and building bus compatibility, making it a reliable choice for energy-saving retrofitting of large fan and pump loads.

ACH550-UH-246A-4驱动器 产品展示
