Bobst 704-1362-02印刷电路板 PDF资料

1.产 品 资 料 介 绍：

Bobst 704-1362-02印刷电路板是Bobst设备中承载多元电子元器件的基板组件，负责信号传输、电源分配及各功能单元之间的互联互通，是设备正常运行的基础保障。

产品特点

1. 采用FR-4阻燃等级板材，防火性能达标

2. 专为Bobst 704-1362-02电路布局设计

3. 板厚1.6mm，机械强度高不易弯曲

4. 走线采用加宽设计，降低大电流通路阻抗

5. 过孔均经沉铜加固处理，导通可靠性好

6. 焊盘采用抗氧化工艺，长期存放不易氧化

7. 板面丝印标注清晰，元件位号一目了然

8. 预留多个测试点，便于故障时逐级排查

9. 边角倒圆处理，安装时不易割伤线缆

10. 安装孔位与Bobst 704-1362-02原机完全一致

11. 具备防插反定位槽，避免错误安装

12. 铜箔附着力强，反复焊接不易脱落

13. 拆机品已目检无烧痕、无断线、无鼓包

14. 常见通讯异常或局部失效可直接替换

15. 帮助恢复设备的基础电路连接与信号通路

结尾

总而言之，Bobst 704-1362-02印刷电路板在板材质量、工艺细节和安装匹配度方面表现扎实，是该电路板故障场景下直接可靠的替换之选。

Bobst 704-1362-02印刷电路板 英文介绍

The Bobst 704-1362-02 printed circuit board is a substrate component that carries multiple electronic components in Bobst equipment. It is responsible for signal transmission, power distribution, and interconnection between various functional units, and is the basic guarantee for the normal operation of the equipment.

Product Features

Using FR-4 flame-retardant grade board, the fire performance meets the standard

Specially designed for Bobst 704-1362-02 circuit layout design

Board thickness 1.6mm, high mechanical strength, not easy to bend

The wiring adopts a widened design to reduce the impedance of high current paths

All through holes have been reinforced with copper plating, ensuring good conductivity and reliability

The solder pad adopts anti-oxidation technology, which is not easy to oxidize after long-term storage

The screen printing label on the board is clear, and the component part numbers are easily visible at a glance

Reserve multiple testing points for step-by-step troubleshooting in case of faults

Rounded corners to prevent cable cuts during installation

The installation hole position is exactly the same as the original Bobst 704-1362-02 machine

Equipped with anti reverse positioning slots to avoid incorrect installation

Copper foil has strong adhesion and is not easily detached after repeated welding

The disassembled product has been visually inspected and found to have no burn marks, broken wires, or bulges

Common communication abnormalities or local failures can be directly replaced

Assist in restoring the basic circuit connections and signal pathways of the device

ending

In summary, the Bobst 704-1362-02 printed circuit board has demonstrated solid performance in terms of board quality, process details, and installation compatibility, making it a reliable and direct replacement option in the event of a circuit board failure.

Bobst 704-1362-02印刷电路板 产品展示
