Bobst 705-OC 输出控制板 PDF资料

1.产 品 资 料 介 绍：

Bobst 705-OC 输出控制板是Bobst设备中负责执行层指令下达的专用板块，将控制系统的逻辑信号转化为驱动电磁阀、继电器、指示灯等执行器件的实际输出。

产品特点

1. 每组输出通道均配备独立熔断保护

2. 专为Bobst 705-OC输出架构定制

3. 板载继电器触点负载能力达5A

4. 输出端与逻辑端采用光耦完全隔离

5. 具备输出对地短路自动截断功能

6. 端子采用防松脱螺丝固定设计

7. 每路输出状态通过高亮LED实时反馈

8. 支持直流与交流负载混合输出配置

9. 输出电压范围宽，适配24V至220V场景

10. 板边预留测试点，便于检修时测量

11. 采用双面覆铜走线，大电流通路更可靠

12. 可直接替换Bobst 705-OC原版旧卡

13. 拆机品已逐路加载测试输出正常

14. 有效解决设备动作缺失或输出不稳定的问题

15. 恢复设备气阀、电机接触器、报警灯等执行功能

结尾

综上，Bobst 705-OC 输出控制板在大电流驱动能力、通道独立保护和输出状态可视性方面表现可靠，是处理Bobst设备输出端故障的高效备件方案。

Bobst 705-OC 输出控制板 英文介绍

The Bobst 705-OC output control board is a specialized module in Bobst equipment responsible for executing layer instructions, converting the logic signals of the control system into actual outputs that drive actuators such as solenoid valves, relays, and indicator lights.

Product Features

Each output channel is equipped with independent fuse protection

Customized for Bobst 705-OC output architecture

The load capacity of the onboard relay contacts reaches 5A

The output end and logic end are completely isolated by optocouplers

Equipped with automatic cutoff function for output to ground short circuit

The terminal adopts anti loosening screw fixation design

Real time feedback of each output status through high brightness LED

Support mixed output configuration of DC and AC loads

Wide output voltage range, suitable for 24V to 220V scenarios

Reserve test points at the edge of the board for easy measurement during maintenance

Adopting double-sided copper-clad wiring, the high current path is more reliable

Can directly replace the original Bobst 705-OC old card

The disassembled products have been loaded and tested one by one, and the output is normal

Effectively solve the problem of missing device actions or unstable output

Restore the execution functions of equipment air valves, motor contactors, alarm lights, etc

ending

Overall, the Bobst 705-OC output control board performs reliably in terms of high current drive capability, channel independent protection, and output status visibility, making it an efficient spare parts solution for handling Bobst equipment output terminal faults.
