HBS01-FPN基座模块 PDF资料
1.产 品 资 料 介 绍：
ABB HBS01-FPN 基座模块用于安装 SD 系列 I/O 模块，提供中性点切换电源，稳定可靠。
中间15条
适用于 DI01、DI02、DO01、DO02 等 SD 系列模块。
提供现场设备电源，采用系统供电。
配备 2 个 16 针接头，接端子排。
TB3 为 5A 熔断端子排，用于电源输入。
支持直连信号线或电缆转接第三方端子排。
水平行内最多接 16 路 I/O 信号。
兼容所有 SD 系列模块及基座。
支持机械键控，防插错模块。
自带锁定装置，固定于 DIN 导轨。
采用 35mm DIN 导轨安装。
工作温度 -20°C 至 70°C（配 DI03）。
支持 DI 与 DO 模块混装。
适用于中性点切换的现场电源场景。
结构紧凑，重量轻。
抗干扰能力强。
结尾
使用 HBS01-FPN 时，断电操作并确认模块类型，可选机械键控防误插。
HBS01-FPN基座模块 英文介绍
The ABB HBS01-FPN base module is used to install SD series I/O modules, providing neutral point switching power supply, which is stable and reliable.
15 in the middle
Suitable for SD series modules such as DI01, DI02, DO01, DO02, etc.
Provide on-site equipment power supply, using system power supply.
Equipped with 2 16 pin connectors for terminal block connection.
TB3 is a 5A fuse terminal block used for power input.
Support direct connection of signal lines or cables to third-party terminal blocks.
Up to 16 I/O signals can be connected within a horizontal line.
Compatible with all SD series modules and bases.
Support mechanical key control and prevent wrong module insertion.
Equipped with a locking device, fixed to the DIN rail.
Installed using 35mm DIN rails.
Working temperature -20 ° C to 70 ° C (with DI03).
Support mixing DI and DO modules.
Suitable for on-site power supply scenarios with neutral point switching.
Compact structure and light weight.
Strong anti-interference ability.
ending
When using HBS01-FPN, power off and confirm the module type, and choose mechanical key control to prevent accidental insertion.
HBS01-FPN基座模块 产品展示
