BOBST 704-1091-04 显示接口板 PDF资料

1.产 品 资 料 介 绍：

BOBST 704-1091-04 显示接口板专为BOBST系列印刷机、模切机等工业设备设计，负责控制单元与显示终端之间的信号转换与传输，具备高兼容性和稳定的图像传输能力，其主要特点如下：

中间（15条）

1. 专为BOBST系列印刷机、模切机、糊盒机等设备设计

2. 负责主控单元与人机界面显示屏之间的信号接口转换

3. 采用高密度表面贴装工艺，集成度高、布局紧凑

4. 多层PCB结构，有效降低电磁干扰，保证视频信号纯净

5. 金手指及连接器采用加厚镀金工艺，耐插拔抗氧化

6. 内置显示信号驱动电路，支持高清分辨率输出

7. 输入端集成ESD静电保护，防止热插拔损坏接口芯片

8. 支持TTL、LVDS或VGA等多种显示信号格式转换

9. 具备显示参数存储功能，保存亮度、对比度等配置

10. 选用工业级宽温元器件，适应印刷车间高温高湿环境

11. 高密度引脚间涂覆阻焊油墨，防止潮湿短路

12. 板载电源及信号锁定状态指示灯，便于现场诊断

13. PCB表面喷涂三防漆，防潮、防尘、耐化学腐蚀

14. 丝印标识清晰，接口定义及跳线功能标注明确

15. 与原厂显示屏完全兼容，可原位替换同型号故障板卡

结尾（总结收束）
总之，BOBST 704-1091-04 是一款稳定可靠的显示接口板，是BOBST设备中连接控制系统与操作界面的关键硬件组件。

BOBST 704-1091-04 显示接口板 英文介绍

The BOBST 704-1091-04 display interface board is designed specifically for industrial equipment such as BOBST series printing machines and die-cutting machines. It is responsible for signal conversion and transmission between control units and display terminals, and has high compatibility and stable image transmission capabilities. Its main features are as follows:

Middle (15 items)

Specially designed for BOBST series printing machines, die-cutting machines, box pasting machines and other equipment

Responsible for signal interface conversion between the main control unit and the human-machine interface display screen

Adopting high-density surface mount technology, high integration and compact layout

Multi layer PCB structure effectively reduces electromagnetic interference and ensures pure video signals

The golden fingers and connectors are made of thickened gold plating technology, which is resistant to insertion and extraction, oxidation and oxidation

Built in display signal driver circuit, supporting high-definition resolution output

Integrated ESD electrostatic protection at the input end to prevent damage to the interface chip caused by hot swapping

Supports conversion of multiple display signal formats such as TTL, LVDS, or VGA

Equipped with display parameter storage function, saving brightness, contrast and other configurations

Select industrial grade wide temperature element devices to adapt to high temperature and high humidity environments in printing workshops

Apply solder mask ink between high-density pins to prevent moisture and short circuits

Onboard power and signal lock status indicator lights for easy on-site diagnosis

Three proof paint is sprayed on the surface of PCB to prevent moisture, dust, and chemical corrosion

Clear silk screen identification, clear interface definition and jumper function labeling

Fully compatible with the original display screen, it can replace faulty boards of the same model in situ

Conclusion (concluding)

In summary, BOBST 704-1091-04 is a stable and reliable display interface board, which is a key hardware component in BOBST devices that connects the control system with the operating interface.

BOBST 704-1091-04 显示接口板 产品展示
