BOBST 704-1097-07通讯 / 信号调理板卡 PDF资料
1.产 品 资 料 介 绍：
BOBST 704-1097-07 通讯/信号调理板卡的主要特点如下：
中间（15条）
双重功能集成：集通讯接口转换与信号调理功能于一体，节约插槽空间。
专机设计：专为 BOBST 系列印刷机、模切机或糊盒机设计，适配特定系统架构。
高速总线通讯：支持与主控制器之间进行高速数据交换（如 CAN 或专用总线）。
信号精准调理：对输入的模拟量（如电压、电流）或脉冲信号进行滤波与线性化处理。
电气隔离保护：通讯端与逻辑控制端通常具备隔离设计，有效抑制现场干扰。
多接口兼容：板载多种物理接口，适配不同规格的传感器或执行器。
低信号失真：采用高精度运算放大器，确保毫伏级微电压信号在传输中不失真。
抗干扰性强：多层 PCB 设计，配合屏蔽措施，适应高电磁干扰的工业环境。
紧凑型尺寸：标准化板卡尺寸，适合 BOBST 设备控制柜的紧凑布局。
坚固耐用：PCB 表面通常涂覆三防漆，防潮、防尘、耐化学腐蚀。
状态可视化：配备通讯状态（TX/RX）及电源指示灯，便于现场排查故障。
即插即用：作为原厂部件，安装后通常无需复杂的底层参数配置。
宽温适应性：选用工业级宽温元器件，适应印刷车间的高温或温差变化。
低功耗设计：整体功耗控制在较低水平，有助于减少控制柜热量积聚。
易于维护：丝印标识清晰，接口定义明确，可直接原位替换同型号故障板卡。
结尾
总之，BOBST 704-1097-07 是一款稳定可靠、集成度高的通讯与信号调理板卡，主要用于确保 BOBST 设备控制系统内部信号传输的准确性与实时性。
BOBST 704-1097-07通讯 / 信号调理板卡 英文介绍
The main features of BOBST 704-1097-07 communication/signal conditioning board are as follows:
Middle (15 items)
Dual function integration: integrating communication interface conversion and signal conditioning functions, saving slot space.
Special machine design: specifically designed for BOBST series printing machines, die-cutting machines, or box pasting machines, adapted to specific system architectures.
High speed bus communication: supports high-speed data exchange with the main controller (such as CAN or dedicated bus).
Accurate signal conditioning: Filter and linearize input analog signals (such as voltage, current) or pulse signals.
Electrical isolation protection: Communication terminals and logic control terminals are usually designed with isolation to effectively suppress on-site interference.
Multi interface compatibility: Onboard multiple physical interfaces to adapt to sensors or actuators of different specifications.
Low signal distortion: High precision operational amplifiers are used to ensure that millivolt level micro voltage signals are not distorted during transmission.
Strong anti-interference ability: multi-layer PCB design, combined with shielding measures, suitable for industrial environments with high electromagnetic interference.
Compact size: Standardized board size, suitable for compact layout of BOBST equipment control cabinets.
Durable and sturdy: PCB surfaces are usually coated with three proof paint, which is moisture-proof, dustproof, and resistant to chemical corrosion.
Status visualization: Equipped with communication status (TX/RX) and power indicator lights for easy on-site troubleshooting.
Plug and play: As an original component, there is usually no need for complex underlying parameter configuration after installation.
Wide temperature adaptability: Industrial grade wide temperature element devices are selected to adapt to high temperatures or temperature differences in the printing workshop.
Low power design: The overall power consumption is controlled at a lower level, which helps reduce the accumulation of heat in the control cabinet.
Easy to maintain: Clear silk screen markings, clear interface definitions, and the ability to directly replace faulty boards of the same model in situ.
ending
In summary, BOBST 704-1097-07 is a stable, reliable, and highly integrated communication and signal conditioning board primarily used to ensure the accuracy and real-time transmission of internal signals in BOBST equipment control systems.
