Silicon Graphics xG24-EK2703A 紧凑型无线开发板 PDF资料
1.产 品 资 料 介 绍：
Silicon Graphics xG24-EK2703A 紧凑型无线开发板基于 EFR32MG24 多协议 SoC 设计，为低功耗物联网设备提供小型化、高集成度的开发平台。
中间（15条）：
搭载 ARM Cortex-M33 内核，主频最高 78 MHz。
板载闪存 1536 KB，RAM 256 KB，满足协议栈与用户代码需求。
原生支持蓝牙低功耗、蓝牙 Mesh、Zigbee 与 Matter 协议。
采用紧凑型单板设计，便于集成到便携或空间受限项目。
板载 SEGGER J-Link 调试器，通过 USB 口即可下载与单步调试。
使用 USB Type-C 接口供电，同时提供虚拟串口功能。
集成 2.4 GHz 陶瓷天线，无需外接天线即可进行射频测试。
设有数据包追踪接口，便于无线通信协议分析。
提供两个用户按键与两个可编程 LED，用于状态指示与交互。
包含复位按键，支持系统快速重启。
引出 mikroBUS 插座，可连接各类 Click 扩展板。
配备 Qwiic 连接器，支持即插即用的 I2C 模块。
提供 GPIO 扩展排针，便于接入外部传感器与执行器。
工作电压 3.3 V，由 USB 直接供电，无需额外电源。
官方定价约为 39 美元，开发与评估成本较低。
结尾：
综上，Silicon Graphics xG24-EK2703A 紧凑型无线开发板以小尺寸、多协议支持和完整调试能力，成为物联网无线原型开发的实用选择。
Silicon Graphics xG24-EK2703A 紧凑型无线开发板 英文介绍
The Silicon Graphics xG24-EK2703A compact wireless development board is designed based on the EFR32MG24 multi protocol SoC, providing a compact and highly integrated development platform for low-power IoT devices.
Middle (15 items):
Equipped with ARM Cortex-M33 core, with a maximum clock frequency of 78 MHz.
The onboard flash memory is 1536 KB and RAM is 256 KB, meeting the protocol stack and user code requirements.
Native support for Bluetooth low power, Bluetooth Mesh, Zigbee, and Matter protocols.
Adopting a compact single board design, it is easy to integrate into portable or space limited projects.
The onboard SEGGER J-Link debugger can be downloaded and debugged through a USB port.
Powered by USB Type-C interface, while providing virtual serial port functionality.
Integrated 2.4 GHz ceramic antenna for RF testing without the need for an external antenna.
Equipped with a packet tracking interface for wireless communication protocol analysis.
Provide two user buttons and two programmable LEDs for status indication and interaction.
Includes a reset button and supports quick system restart.
Introduce the mikroBUS socket, which can be connected to various Click expansion boards.
Equipped with Qwiic connectors, supporting plug and play I2C modules.
Provide GPIO extension pins for easy access to external sensors and actuators.
The working voltage is 3.3 V, directly powered by USB, without the need for additional power supply.
The official pricing is around $39, with lower development and evaluation costs.
ending:
In summary, the Silicon Graphics xG24-EK2703A compact wireless development board has become a practical choice for IoT wireless prototype development due to its small size, multi protocol support, and complete debugging capabilities.
Silicon Graphics xG24-EK2703A 紧凑型无线开发板 产品展示
