Silicon Graphics 030-0686-004图形控制板卡 PDF资料
1.产 品 资 料 介 绍：
Silicon Graphics 030-0686-004 图形控制板卡基于高性能图形处理架构设计，主要用于 SGI 系列工作站或图形服务器，提供高带宽图形数据与显示输出能力。
中间（15条）：
板卡采用专用图形处理芯片，支持 2D/3D 硬件加速渲染。
搭载独立显存，用于帧缓冲与纹理数据暂存，减轻系统负担。
支持高色深与高分辨率显示输出，满足专业图像与 CAD 设计需求。
接口采用 SGI 专有图形总线形式，适配对应型号的背板与主板插槽。
具备几何处理能力，可加速三维模型变换与光照计算。
支持双路或单路显示器输出，接口形式以专用 DVI 或模拟接口为主。
板载视频查找表，实现伽马校正及色彩空间转换。
提供硬件光标叠加层，提升交互响应速度。
支持 OpenGL 等专业图形 API，兼容 SGI 原有 IRIX 系统下的图形环境。
设计有被动散热片或主动风扇接口，适配机箱风道。
可配合纹理内存扩展模块，提升复杂场景下的贴图性能。
支持立体显示输出，满足科学可视化与医疗影像需求。
固件中存储 VGA 兼容模式，便于系统早期调试与文本显示。
支持单卡或多卡协同，用于多屏拼接或分区渲染。
板卡驱动集成于 IRIX 系统内核中，识别后即可调用图形管线。
结尾：
综上，Silicon Graphics 030-0686-004 图形控制板卡依托 SGI 原生图形架构，为专业可视化与计算图形场景提供了稳定且高效的显示与加速能力。
Silicon Graphics 030-0686-004图形控制板卡 英文介绍
The Silicon Graphics 030-0686-004 graphics control board is designed based on a high-performance graphics processing architecture and is mainly used for SGI series workstations or graphics servers, providing high bandwidth graphics data and display output capabilities.
Middle (15 items):
The board adopts a dedicated graphics processing chip and supports 2D/3D hardware accelerated rendering.
Equipped with independent video memory for frame buffering and temporary storage of texture data, reducing system burden.
Supports high color depth and high-resolution display output, meeting the needs of professional image and CAD design.
The interface adopts SGI proprietary graphics bus form, adapted to the corresponding model of backplane and motherboard slots.
Capable of geometric processing, able to accelerate 3D model transformation and lighting calculation.
Supports dual or single channel display output, with dedicated DVI or analog interfaces as the main interface form.
Onboard video lookup table for gamma correction and color space conversion.
Provide hardware cursor overlay layer to improve interaction response speed.
Supports professional graphics APIs such as OpenGL and is compatible with the graphics environment of SGI's original IRIX system.
Designed with passive heat sinks or active fan interfaces, compatible with chassis air ducts.
Can be combined with texture memory expansion module to improve mapping performance in complex scenes.
Support stereoscopic display output to meet the needs of scientific visualization and medical imaging.
The firmware stores VGA compatibility mode for early system debugging and text display.
Support single card or multi card collaboration for multi screen splicing or partition rendering.
The board driver is integrated into the IRIX system kernel, and once recognized, it can call the graphics pipeline.
ending:
In summary, the Silicon Graphics 030-0686-004 graphics control board relies on the SGI native graphics architecture to provide stable and efficient display and acceleration capabilities for professional visualization and computing graphics scenes.
Silicon Graphics 030-0686-004图形控制板卡 产品展示
