DINKLE DM37-AP01 1360278连接模块 PDF资料
1.产 品 资 料 介 绍：
DINKLE DM37-AP01 1360278连接模块产品特点
DINKLE DM37-AP01是一款高密度信号转接模块，专为需要大量I/O点位的工业控制系统设计，将DB37接口与町洋双层端子结合于一体。其核心特点如下：
采用DB37接口，支持多达37路信号同时转接。
适配37芯标准并口线缆，兼容性强。
上下两层独立走线设计，有效区分不同信号类型。
每路均配有清晰丝印编号，查线一目了然。
外壳采用阻燃工程塑料，符合安规要求。
金属螺丝采用防锈处理，长期使用不滑牙。
接线端子带有防误插结构，避免接错线。
背部带安装卡扣，免工具固定于导轨。
上下端子开口方向相反，便于分层接线。
支持数字量及模拟量混合信号接入。
通过跳线或短路片可实现公共端快速连接。
体积紧凑，比同点数普通端子节省约30%空间。
螺丝带有自升压结构，导线不易松脱。
附带空白标记条，便于现场自定义标识。
适用于数控机床、测试台及自动化产线的集中接线。
综上所述，DM37-AP01凭借高密度设计、清晰的信号区分及便捷的现场标识能力，是多点数I/O集中转接的高效解决方案。
DINKLE DM37-AP01 1360278连接模块 英文介绍
DINKLE DM37-AP01 1360278 Connection Module Product Features
DINKLE DM37-AP01 is a high-density signal conversion module designed for industrial control systems that require a large number of I/O points. It combines the DB37 interface with the Machio double-layer terminal. Its core features are as follows:
Adopting DB37 interface, supporting up to 37 signals to be switched simultaneously.
Compatible with 37 core standard parallel port cables, with strong compatibility.
The independent wiring design of the upper and lower layers effectively distinguishes different signal types.
Each route is equipped with clear silk screen numbers, making it easy to check the lines at a glance.
The shell is made of flame-retardant engineering plastic, which meets safety regulations.
The metal screws are treated with rust prevention and will not slip teeth after long-term use.
The wiring terminal is equipped with an anti misoperation structure to avoid misconnection of wires.
The back is equipped with a buckle for installation, which can be fixed to the guide rail without tools.
The opening directions of the upper and lower terminals are opposite, making it convenient for layered wiring.
Support mixed signal access of digital and analog signals.
Fast connection of the common end can be achieved through jumper wires or short-circuit plates.
Compact in size, saving about 30% space compared to ordinary terminals with the same number of points.
The screw has a self boosting structure, making it difficult for the wire to loosen.
Comes with blank markers for easy on-site customization of identification.
Suitable for centralized wiring of CNC machine tools, testing benches, and automated production lines.
In summary, DM37-AP01 is an efficient solution for multi point I/O centralized conversion due to its high-density design, clear signal differentiation, and convenient on-site identification capability.
