Silicon 80166F3-01 CPU 主控板 PDF资料
1.产 品 资 料 介 绍：
Silicon 80166F3-01 实际由SVG Silicon Valley Group制造，是用于ASML SVG 90S DUV光刻系统的CPU主控板，负责控制半导体制造设备中的工作站运行。
品牌归属SVG Silicon Valley Group，非SGI产品
Silicon 80166F3-01 用于ASML SVG 90S DUV光刻系统
型号编号为80166F3-01，存在多个变体版本
有多种固件配置版本，如CP、DEV、IDX、PVB、VB、VP等
Silicon 80166F3-01 对应EPROM型号含740172-44（CP版本）
称为Station CPU BD或Station Processor CPU PCB卡
物理尺寸为标准PCB板卡形态
采用多层印刷电路板工艺制造
Silicon 80166F3-01 属于半导体制造设备的现场可更换单元
板载EPROM芯片存储固件和校验信息
不同版本固件校验码各异
可作为9039型真空烘烤站的组成部件使用
Silicon 80166F3-01 与系统内传感器板卡协同工作
符合半导体设备行业标准
属于光刻系统中负责工作站控制的核心组件
Silicon 80166F3-01 作为半导体光刻系统的CPU主控板，是ASML SVG 90S DUV设备中负责工作站控制的核心组件。
Silicon 80166F3-01 CPU 主控板 英文介绍
Silicon 80166F3-01 is actually manufactured by SVG Silicon Valley Group and is a CPU control board used in ASML SVG 90S DUV lithography systems, responsible for controlling the operation of workstations in semiconductor manufacturing equipment.
The brand belongs to SVG Silicon Valley Group and is not an SGI product
Silicon 80166F3-01 is used for ASML SVG 90S DUV lithography system
The model number is 80166F3-01, and there are multiple variant versions available
There are multiple firmware configuration versions, such as CP, DEV, IDX, PVB, VB, VP, etc
Silicon 80166F3-01 corresponds to EPROM models including 740172-44 (CP version)
Known as Station CPU BD or Station Processor CPU PCB card
The physical dimensions are in the form of standard PCB boards
Manufacturing using multi-layer printed circuit board technology
Silicon 80166F3-01 is a field replaceable unit for semiconductor manufacturing equipment
Onboard EPROM chip stores firmware and verification information
Different versions of firmware have different verification codes
Can be used as a component of the 9039 vacuum baking station
Silicon 80166F3-01 works in conjunction with sensor boards within the system
Compliant with semiconductor equipment industry standards
Belonging to the core component responsible for workstation control in the lithography system
Silicon 80166F3-01, as the CPU main control board of semiconductor lithography system, is the core component responsible for workstation control in ASML SVG 90S DUV equipment.
Silicon 80166F3-01 CPU 主控板 产品展示
