Silicon Graphics Si5350/51-20QFN-EVB 发生器评估板 PDF资料

1.产 品 资 料 介 绍：

Silicon Graphics Si5350/51-20QFN-EVB 是Silicon Labs推出的Si5350/Si5351时钟发生器评估板，用于评估任意频率CMOS时钟生成器的性能。

1. 专为评估Si5350/Si5351时钟发生器设计

2. Silicon Graphics Si5350/51-20QFN-EVB 预装20-QFN封装芯片

3. 单USB端口供电，无需外接电源

4. 板载27MHz晶体，支持异步独立运行

5. 可通过CLKIN SMA接口同步外部时钟参考

6. Silicon Graphics Si5350/51-20QFN-EVB 跳线可选1.8V、2.5V或3.3V工作电压

7. 板载MCU负责编程Si535x时序IC

8. 配合ClockBuilder桌面软件配置频率

9. MCU可测量并上报芯片电流消耗

10. Silicon Graphics Si5350/51-20QFN-EVB 支持I2C总线外部控制

11. 提供8路时钟输出（CLK0-CLK7）

12. 配备三颗状态LED（就绪/繁忙/故障）

13. 预留SMA接口和测试点用于连接外部设备

14. 可通过ClockBuilder Pro配置以模拟其他封装选项

15. Silicon Graphics Si5350/51-20QFN-EVB 输出频率范围0.0025~200MHz

Silicon Graphics Si5350/51-20QFN-EVB 作为时钟发生器评估平台，为开发人员提供了灵活的频率生成与测试能力。

Silicon Graphics Si5350/51-20QFN-EVB 发生器评估板  英文介绍

Silicon Graphics Si5350/51-20QFN-EVB is a Si5350/Si5351 clock generator evaluation board launched by Silicon Labs, used to evaluate the performance of any frequency CMOS clock generator.

Specially designed for evaluating Si5350/Si5351 clock generators

Silicon Graphics Si5350/51-20QFN-EVB pre installed with 20-QFN package chip

Single USB port power supply, no need for external power supply

Onboard 27MHz crystal, supports asynchronous independent operation

External clock reference can be synchronized through the CLKIN SMA interface

Silicon Graphics Si5350/51-20QFN-EVB jumper with optional operating voltages of 1.8V, 2.5V, or 3.3V

On board MCU is responsible for programming Si535x timing IC

Cooperate with ClockBuilder desktop software configuration frequency

MCU can measure and report chip current consumption

Silicon Graphics Si5350/51-20QFN-EVB supports I2C bus external control

Provide 8 clock outputs (CLK0-CLK7)

Equipped with three status LEDs (ready/busy/faulty)

Reserved SMA interface and testing points for connecting external devices

Can be configured through ClockBuilder Pro to simulate other packaging options

Silicon Graphics Si5350/51-20QFN-EVB output frequency range 0.0025-20MHz

Silicon Graphics Si5350/51-20QFN-EVB serves as a clock generator evaluation platform, providing developers with flexible frequency generation and testing capabilities.

Silicon Graphics Si5350/51-20QFN-EVB 发生器评估板  产品展示
