Silicon Graphics 030-1054-001  I/O 控制板 PDF资料

1.产 品 资 料 介 绍：

Silicon Graphics 030-1054-001 是一款用于SGI Origin/Onyx系列系统的I/O控制板，负责管理外部存储与数据通道。

1. 采用SGI专有XIO或GIO总线接口

2. 集成Ultra160或Ultra320 SCSI控制器

3. Silicon Graphics 030-1054-001 提供双独立SCSI通道

4. 内置独立DMA引擎，减轻CPU负载

5. 板载Boot ROM，固件针对IRIX优化

6. 支持热插拔，符合SGI高密度机箱规范

7. 核心芯片覆盖散热片，配合风道散热

8. Silicon Graphics 030-1054-001 设有跳线或DIP开关配置SCSI ID

9. 板载LED指示灯，便于故障诊断

10. 采用SGI现场更换单元（FRU）物理规范

11. 通常与处理器板（如030-0804-101）协同工作

12. 支持连接外部磁盘阵列或磁带机

13. 具备完整硬件错误记录与报告能力

14. Silicon Graphics 030-1054-001 兼容多款Origin/Onyx同系机型

15. 驱动与IRIX内核深度集成，支持在线识别

Silicon Graphics 030-1054-001 通过SCSI通道与DMA设计，为SGI系统提供了可靠的外部存储扩展能力。

Silicon Graphics 030-1054-001  I/O 控制板  英文介绍

Silicon Graphics 030-1054-001 is an I/O control board for SGI Origin/Onyx series systems, responsible for managing external storage and data channels.

Adopting SGI proprietary XIO or GIO bus interface

Integrate Ultra160 or Ultra320 SCSI controllers

Silicon Graphics 030-1054-001 provides dual independent SCSI channels

Built in independent DMA engine to reduce CPU load

Onboard Boot ROM, firmware optimized for IRIX

Supports hot swapping and complies with SGI high-density chassis specifications

Core chip covering heat sink, combined with air duct heat dissipation

Silicon Graphics 030-1054-001 is equipped with jumper or DIP switch to configure SCSI ID

Onboard LED indicator light for easy fault diagnosis

Adopting SGI on-site replacement unit (FRU) physical specifications

Usually works in conjunction with processor boards (such as 030-0804-101)

Support connecting external disk arrays or tape drives

Capable of recording and reporting complete hardware errors

Silicon Graphics 030-1054-001 is compatible with multiple Origin/Onyx models in the same series

Deep integration of driver and IRIX kernel, supporting online recognition

Silicon Graphics 030-1054-001 provides reliable external storage expansion capabilities for SGI systems through SCSI channels and DMA design.

Silicon Graphics 030-1054-001  I/O 控制板  产品展示
