Continental CICP1800RB继电器扩展板 PDF资料
1.产 品 资 料 介 绍：
Continental CICP1800RB 是一款继电器扩展板，专为工业控制系统中的信号隔离与负载驱动而设计，可有效扩展主控单元的输出能力。
产品特点（15条）：
CICP1800RB 提供 8 个继电器输出通道，满足多路负载控制需求
每个继电器触点容量为 10A/250V AC 或 10A/30V DC，适配常见工业负载
采用 SPDT（单刀双掷）触点形式，支持常开和常闭两种接线方式
输入信号与输出触点之间采用光耦隔离，增强系统抗干扰能力
输入电压范围 12-24V DC，兼容主流 PLC 和控制器输出电平
每个通道配有独立的 LED 指示灯，清晰显示继电器吸合状态
支持 DIN 导轨安装，现场装配方便快捷
工作温度范围 -20°C 至 +55°C，适应一般工业环境
防护等级 IP20，适合安装在控制柜内使用
Continental CICP1800RB 采用可插拔式接线端子，便于现场接线与维护
触点机械寿命达 2000 万次以上，电气寿命达 10 万次以上
内置续流二极管，有效抑制感性负载断开时的反向电动势
模块宽度约 72 mm（4 个模数单位），占用控制柜空间小
每个通道可独立控制，互不干扰，配置灵活
输入电流每通道约 10-15 mA，对主控单元负载影响小
结尾：综上所述，CICP1800RB 凭借 8 路 10A 继电器输出、光耦隔离及紧凑的 DIN 导轨设计，是工业控制系统中信号扩展与负载驱动的可靠选择。
Continental CICP1800RB继电器扩展板 英文介绍
Continental CICP1800RB is a relay expansion board designed specifically for signal isolation and load driving in industrial control systems, which can effectively expand the output capability of the main control unit.
Product features (15 items):
CICP1800RB provides 8 relay output channels to meet the requirements of multi-channel load control
Each relay contact has a capacity of 10A/250V AC or 10A/30V DC, suitable for common industrial loads
Adopting SPDT (single pole double throw) contact form, supporting two wiring modes: normally open and normally closed
Optocoupler isolation is used between the input signal and the output contact to enhance the system's anti-interference ability
Input voltage range 12-24V DC, compatible with mainstream PLC and controller output levels
Each channel is equipped with an independent LED indicator light, which clearly displays the relay engagement status
Support DIN rail installation, easy and fast on-site assembly
Working temperature range -20 ° C to+55 ° C, suitable for general industrial environments
Protection level IP20, suitable for installation in control cabinets for use
The Continental CICP1800RB adopts pluggable terminal blocks for easy on-site wiring and maintenance
The mechanical lifespan of the contacts is over 20 million times, and the electrical lifespan is over 100000 times
Built in freewheeling diode effectively suppresses the reverse electromotive force when the inductive load is disconnected
The module width is about 72 mm (4 modular units), occupying a small space in the control cabinet
Each channel can be independently controlled without interfering with each other, with flexible configuration
The input current per channel is about 10-15 mA, which has little impact on the load of the main control unit
Conclusion: In summary, CICP1800RB is a reliable choice for signal expansion and load driving in industrial control systems due to its 8-channel 10A relay output, optocoupler isolation, and compact DIN rail design.
Continental CICP1800RB继电器扩展板 产品展示
